Round-the-clock Perimeter Protection With Bosch Dinion Infrared Imager

Product Profile

The new Dinion Infrared Imager from Bosch overcomes all the challenges posed by critical infrastructure surveillance.

Capable of providing up to 160m (525ft) of detection level surveillance and 120m (390ft) of classification level surveillance in total darkness at night, the camera is ideal for installation along a fenceline or perimeter. All Dinion Infrared Imager cameras are tested to DCRI standard surveillance levels - Detection, Classification, Recognition and Identification of target - to ensure reliable performance at the stated distances.

Unrivalled image quality

Poor lighting conditions can prevent effective 24/7 perimeter surveillance. The Dinion Infrared Imager combines 2X-Dynamic technology for 20-bit processing and wide dynamic range with our advanced infrared technology in a single, robust outdoor unit to deliver unmatched image quality night and day.

Our innovative 3D Diffuser infrared technology balances scene foreground and background for perfectly evenly illuminated night-time images. Unique Constant Light technology automatically compensates for naturally-occurring LED degradation to ensure a consistent level of lighting performance for the life of the camera. New Variable Field Illumination reduces installation time and delivers total flexibility, by allowing you to easily adjust IR intensity and beam patterns on-site.

Easy installation

A quick connect system between the camera and mount makes it quick and easy to install. The camera can be fully configured without exposure to the elements, an integrated on-screen display with remote capabilities provides a single interface for controlling most infrared and camera functions.

Advanced intelligence

Need help detecting loitering, line crossing and other potential threats? Embedded Intelligent Video Analysis (IVA) processes video signals and alerts operators to potential security threats, allowing the camera to function as a reliable, automated fence-line detection appliance.

Install and forget

The unit is rated to IP67 and NEMA4X for corrosion resistance and tested to desert solar radiation conditions, shock and vibration. It is designed to stay securely in place even through hurricane-force winds.

The Dinion Infrared Imager overcomes all the challenges posed by perimeter, border and general monitoring surveillance at critical infrastructure sites to deliver round-the-clock protection you can rely on.
Read more

Technical Specification

Make Bosch
Manufacturer Bosch Security Systems
Model code VEI-308V05-12W
Color Type Color / Monochrome
Resolution TVL 540
Specialist Types Infrared
Auto Iris Yes
Sensitivity lux 48 lx
Motion Activated Yes
White Balance Yes
S/ N (Signal/ Noise) Ratio dB 50
Signal Mode Pal, NTSC
Physical Specifications Dimension mm: 402 x 193 x 310
Weight g: 6,500
Additional info Dinion Infrared Imager is a rugged, active infrared surveillance camera designed to master perimeter surveillance and other outdoor low-light applications.
