Bosch LTC 8540/00 Alarm Interface Unit

Technical Specification

Features:

Make: Bosch
Model code: LTC 8540/00
Alarm Inputs: 64
Voltage: 12 V DC
Power Consumption: 8 W

Additional info:

Bosch LTC 8540/00 alarm interface unit accepts up to 64 contact closures or logic level inputs from remote sensing devices such as door contacts, PIRs, etc. and then reports the “alarm” information to the main Allegiant CPU bay. Alarm inputs may be configured in groups of 32 to accept either normally open or normally closed contacts. Unit also contains eight relay outputs that activate automatically upon alarm conditions. A two meter (6 ft) interface cable for data/power between unit and main CPU bay is supplied.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Bosch
Manufacturer	Bosch Security Systems
Category	Video Surveillance>Telemetry transmitters and controllers
Model code	LTC 8540/00
Alarm Inputs	64
Electrical Specifications	Voltage: 12 V DC Power Consumption: 8 W
Physical Specifications	Dimensions mm: 445 x 318 x 89 Weight g: 1,800
Additional info	Bosch LTC 8540/00 alarm interface unit accepts up to 64 contact closures or logic level inputs from remote sensing devices such as door contacts, PIRs, etc. and then reports the “alarm” information to the main Allegiant CPU bay. Alarm inputs may be configured in groups of 32 to accept either normally open or normally closed contacts. Unit also contains eight relay outputs that activate automatically upon alarm conditions. A two meter (6 ft) interface cable for data/power between unit and main CPU bay is supplied.
