Bosch ISP-EM55SM-120 Surface Mounting LSN 2 Zone Expander Module

Technical Specification

Features:

Make: Bosch
Model code: ISP-EM55SM-120
Control Panels & Accessories: Yes
Accessories: LSN 2 Zone Expander Module
Dimensions mm: 76 x 25

Additional info:

For monitored connection of conventional detectors (2 primary lines) on the local security network LSN The point type can be programmed in the control panel Onboard internal EOL 12.1 kΩ resistors The circuit board is equipped with a tamper contact

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Bosch
Manufacturer	Bosch Security Systems
Category	Intruder Alarms>Intruder alarm system control panels & accessories
Model code	ISP-EM55SM-120
Control Panels & Accessories	Yes
Accessories	LSN 2 Zone Expander Module
Physical Specifications	Dimensions mm: 76 x 25
Environmental Specifications	Operating Temp ^oC: 0 ~ 50 C (32 ~ 122 F)
Additional info	For monitored connection of conventional detectors (2 primary lines) on the local security network LSN The point type can be programmed in the control panel Onboard internal EOL 12.1 kΩ resistors The circuit board is equipped with a tamper contact
