Bosch ARD-AYBS6280 Proximity Reader

Technical Specification

Features:

Make: Bosch
Model code: ARD-AYBS6280
Series: LECTUS duo 3000 EV1 line
Reader Type: Proximity
Standalone/ Networkable: Networkable

Additional info:

RS485/OSDP and 26 Bit Wiegand interface Supports the data record of Bosch coded MIFARE classic and DESFire EV1 cards and keyfobs and CSN of ISO14443A credentials Three LED indicators and a beeper give clear feedback to the user during operation IP65 rated for indoor and outdoor use Wall or mullion mount Tamper switch

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Bosch
Manufacturer	Bosch Security Systems
Model code	ARD-AYBS6280
Series	LECTUS duo 3000 EV1 line
Reader Type	Proximity
Standalone/ Networkable	Networkable
IP Rating	IP65
Mount Type	Mullion
LED / Beep	LED / Beep
Wiegand Interface	Yes
Electrical Specifications	Voltage: 8.5 ~ 16 V DC
Physical Specifications	Dimensions mm: 137 x 44 x 28 Weight g: 220
Environmental Specifications	Operating Temp ^oC: -25 ~ 65 C (-13 ~ 149 F) Operating Humidity %: 0 ~ 95
Protection	IP65
Additional info	RS485/OSDP and 26 Bit Wiegand interface Supports the data record of Bosch coded MIFARE classic and DESFire EV1 cards and keyfobs and CSN of ISO14443A credentials Three LED indicators and a beeper give clear feedback to the user during operation IP65 rated for indoor and outdoor use Wall or mullion mount Tamper switch
