Vicon V972D-N312IR Megapixel Outdoor Fixed Dome
Technical Specification
Make | Vicon |
---|---|
Manufacturer | Vicon Industries |
Category | Video Surveillance>IP Dome cameras |
Model code | V972D-N312IR |
Chip Inch Size | 1/3 |
Color Type | True Day / Night |
Resolution TVL | 1920 x 1080 |
HD | Yes |
Megapixel | Yes |
Sensitivity lux | 0 ~ 0.4 |
Digital (DSP) | Yes |
Mount Type | In-ceiling, surface |
Electrical Specifications |
Voltage: 12 V DC / PoE Power Consumption: 6.5 ~ 7.4 W |
Focal length | 2.8 ~ 12 mm |
Compression | H.264, M-JPEG, CBR, VBR |
Back Light Compensation | Yes |
White Balance | Yes |
Electronic Shutter range | 1/10,000 ~ 1s |
S/ N (Signal/ Noise) Ratio dB | 72 |
Built-in IR LED | Yes |
Network Properties |
Interface: 10Base-T, 100Base-TX, RJ-45 Network Protocols: IPv4, IPv6, TCP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, DNS, DDNS, UDP, ARP Control: PTZ Image Frame Rate: 30 fps |
Physical Specifications |
Dimensions mm: 143 x 114 Weight g: 800 |
Environmental Specifications |
Operating Temp oC: -20 ~ +60 C (-4 ~ +140 F) Operating Humidity %: < 90 Protection: IP66, IK10 |
