Uniview (UNV) UAC-D115-F40 5MP Fixed IR Dome Analog Camera
Technical Specification
- Make: Uniview (UNV)
- Model code: UAC-D115-F40
- Series: Dolphin Series
- Color Type: Color / Monochrome
- Resolution TVL: 5 MP
High quality imaging with 5MP resolution TVI/AHD/CVI/CVBS Supports IR-cut filter with auto-switch (ICR) Supports 180° horizontal flip, 180° vertical flip OSD configuration menu, easy to operate IP67 waterproof and dustproof design, high reliability OSD configuration menu in 11 languages 3-Axis
Read more| Make | Uniview (UNV) |
|---|---|
| Manufacturer | Zhejiang Uniview Technologies Co.,Ltd |
| Category | Video Surveillance>Dome cameras |
| Model code | UAC-D115-F40 |
| Series | Dolphin Series |
| Color Type | Color / Monochrome |
| Resolution TVL | 5 MP |
| Dome Type | Fixed |
| Sensitivity lux | 0.02 lux (F2.0, AGC ON) ; 0 lux (IR on) |
| Mount Type | Wall, Pole, Corner, Pendant |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: MAX 3.4W |
| Focal length | 4.0 mm |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s |
| Video Output | BNC, supports TVI/AHD/CVI/CVBS |
| Physical Specifications |
Dimensions mm: Φ111 x 83 Weight g: 233g |
| Environmental Specifications |
Operating Temp oC: -30 ~ +60 C (-22 ~ +140 F) Operating Humidity %: ≤ 95% Protection: IP67 |
Product description
The Uniview UAC-D115-F40 is a robust 5MP HD IR fixed dome analog camera, ideal for comprehensive surveillance solutions. Featuring a high-performance 1/2.7-inch CMOS sensor, this camera offers superior image quality, accommodating a range of video standards including TVI, AHD, CVI, and CVBS. This ensures optimal versatility in diverse networking environments. Equipped with a SYV-75-3 or other coaxial cable types, it supports long-distance transmission with minimal interference, delivering clear, low-delay mega-pixel video output.
Key Features
- High-resolution imaging with a 5MP sensor for detailed and crisp visuals.
- Seamless adaptability to various video output formats: TVI, AHD, CVI, CVBS.
- IR-cut filter with auto-switch function, providing color imaging by day and black and white at night.
- Comprehensive flip options: 180° horizontal and vertical, enhancing installation flexibility.
- OSD configuration menu available in 11 languages, ensuring user-friendly operation.
- IP67-rated waterproof and dustproof protection for reliable outdoor use.
Ideal Use Cases
The Uniview UAC-D115-F40 is best suited for outdoor surveillance in various environments due to its IP67-rated durability. With superior image clarity and the ability to function under extreme temperatures ranging from -22°F to 140°F, it caters excellently to locations demanding high reliability, such as industrial sites, public areas, and critical infrastructure.
Specifications
- Lens Options: 4.0 mm with an angle of view (H/V/D) of 82.9°/46.1°/100.0°.
- Effective illumination range of up to 20m with long-lasting IR technology.
- Wide dynamic range support via DWDR and 2D digital noise reduction.
- Protected from power surges with 4kV surge protection for power and video output.
