Panasonic WVCP480/4 Surveillance camera

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Features:

Make: Panasonic
Model code: WVCP480/4
Series: Super Dynamic III
Chip Inch Size ": 1/3
Color Type: Color / Monochrome

Additional info:

Panasonic introduces the new WV-CP480 Series Super Dynamic III cameras, equipped with Auto Back Focus (ABF). When these cameras switch from colour to B/W mode, the cameras automatically make micron-order adjustments in CCD position to achieve precise back focus. The new Auto Back Focus (ABF) technology ensures delivery of clear, sharp, perfectly focused images 24-hours a day, automatically.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Panasonic
Manufacturer	Panasonic Corporation of North America
Category	Video Surveillance>Surveillance cameras
Model code	WVCP480/4
Chip Inch Size "	1/3
Color Type	Color / Monochrome
Resolution TVL	570
Sensitivity lux	0.08
Lens Mount	CS
Electrical Specifications	Voltage: 220 ~ 240 V AC Power Consumption: 4.6 W
Motion Activated	Yes
Picture Elements HxV	753 x 582
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Electronic Shutter range	1/50 ~ 1/10,000
S/ N (Signal/ Noise) Ratio dB	50
Synchronisation	Internal, Line-lock
Signal Mode	PAL/NTSC
Video Output	1.0 Vp-p, 75 Ohms
Physical Specifications	Dimension mm: 70 x 65 x 129 Weight g: 520
Environmental Specifications	Operating Temperature ^oC: -10 - +50
Additional info	Panasonic introduces the new WV-CP480 Series Super Dynamic III cameras, equipped with Auto Back Focus (ABF). When these cameras switch from colour to B/W mode, the cameras automatically make micron-order adjustments in CCD position to achieve precise back focus. The new Auto Back Focus (ABF) technology ensures delivery of clear, sharp, perfectly focused images 24-hours a day, automatically.
