LILIN PIH-0128P8 1/3 Inch Ultrahigh Sensitivity 40M IR Camera

Technical Specification

Features:

Make: LILIN
Model code: PIH-0128P8
Chip Inch Size ": 1/3
Color Type: Color / Monochrome
Resolution TVL: 420

Additional info:

LILIN PIH-0128P8 1/3 inch ultrahigh sensitivity 40M IR camera is a day/night camera. The camera features unique front glass design that separates the lens from IR LEDs, automatically activates LED when light drops below10 Lux, aluminum housing with IP66 rating, Aluminum PCB for fast heat dissipation.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	LILIN
Manufacturer	LILIN
Category	Video Surveillance>Surveillance cameras
Model code	PIH-0128P8
Chip Inch Size "	1/3
Color Type	Color / Monochrome
Resolution TVL	420
Digital (DSP)	Yes
Specialist Types	Infrared
Electrical Specifications	Voltage: 90 ~ 260 V AC Power Consumption: 10 W
Focal Length mm	8.0
Picture Elements HxV	510 x 492
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Gamma Correction	y=0.45
Electronic Shutter range	1/60(1/50) ~ 1/100,000 s
S/ N (Signal/ Noise) Ratio dB	>50
Synchronisation	Internal
Signal Mode	PAL, NTSC
Video Output	CVBS 1.0Vp-p, 75 ohm
Physical Specifications	Dimension mm: 100 x 235 Weight g: 1,500
Environmental Specifications	Operating Temperature ^oC: -35 ~ +50 C (-31 ~ +122 F) Protection: IP66
Additional info	LILIN PIH-0128P8 1/3 inch ultrahigh sensitivity 40M IR camera is a day/night camera. The camera features unique front glass design that separates the lens from IR LEDs, automatically activates LED when light drops below 10 Lux, aluminum housing with IP66 rating, Aluminum PCB for fast heat dissipation.
