Hikvision DS-6716HFI 16-ch, BNC Video Encoder

Technical Specification

Features:
  • Make: Hikvision
  • Model code: DS-6716HFI
  • Video Inputs: 16
  • Data Input: Yes
  • Audio Input: Yes
Read more
Additional info:

DS-6716HFI is a video encoder featuring H.264/MPEG4/MPEG2/MJPEG encoding standards, up to 4CIF real-time encoding and multiple PTZ protocols.

Read more
Make Hikvision
Manufacturer Hikvision USA Inc.
Model code DS-6716HFI
Video Inputs 16
Data Input Yes
Audio Input Yes
Alarm Input Yes
Compression Type H.264/ JPEG /M-JPEG/MPEG-4
Network Protocols IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, hkDDNS, NTP, RTSP, RTP/RTCP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SOCKSv4/v5, PSIA, OnVIF, Hik CGI, netFilter
Interface 1 RJ-45 10 M / 100 Mbps
Image per second (IPS) 30
Physical Specifications Dimensions mm: 440 x 45 x 274
Weight g: 4,000
Electrical Specifications Power Consumption: 22 W
Voltage: 12 V DC
Environmental Specifications Operating Temperature oC: -10 ~ +55 C (14 ~ 131 F)
Operating Humidity %: 10 ~ 90
Additional info DS-6716HFI is a video encoder featuring H.264/MPEG4/MPEG2/MJPEG encoding standards, up to 4CIF real-time encoding and multiple PTZ protocols.
