eneo EKR-32/8 CCTV switcher
Technical Specification
Features:
- Make: eneo
- Model code: EKR-32/8
- Video inputs / ports: 32
- Video Outputs: 8
- No of Alarms: 32
Additional info:
Up to 32 Inputs / 8 Outputs. Multiple Language On-Screen Menu Driven Set-up. Time/Date/Text Insertion. Group Call-up for Cameras/Monitors. Programmable Camera Sequences incl. Preset Calls.
Read more| Make | eneo |
|---|---|
| Manufacturer | eneo |
| Category | Video Surveillance>Switchers & Switches |
| Model code | EKR-32/8 |
| Video inputs / ports | 32 |
| Video Outputs | 8 |
| No of Alarms | 32 |
| Switching Type | Sequential |
| TX/RX | RX/TX |
| Bandwidth MHz | 6 |
| Cross Talk dB | 47 |
| Detector Range m | 15 |
| Video Signal V, ohms | 1 Vp-p, 75 Ohms |
| Termination | BNC |
| Physical Specifications |
Dimensions mm: 90 x 430 x 180 Weight g: 3.2 kg |
| Electrical Specifications |
Voltage: 240 V AC Power Consumption: 24 W |
| Environmental Specifications | Operating Temperature oC: 0 ~ 45 |
| Analog Switcher Type | Matrix Switchers |
| Additional info |
Up to 32 Inputs / 8 Outputs. Multiple Language On-Screen Menu Driven Set-up. Time/Date/Text Insertion. Group Call-up for Cameras/Monitors. Programmable Camera Sequences incl. Preset Calls. |
