eneo EKR-16/4 CCTV switcher

Technical Specification

Features:

Make: eneo
Model code: EKR-16/4
Video inputs / ports: 16
Video Outputs: 4
No of Alarms: 16

Additional info:

Multiple Language On-Screen Menu Driven Set-up. Time/Date/Text Insertion. Group Call-up for Cameras/Monitors. Programmable Camera Sequences incl. Preset Calls.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	eneo
Manufacturer	eneo
Category	Video Surveillance>Switchers & Switches
Model code	EKR-16/4
Video inputs / ports	16
Video Outputs	4
No of Alarms	16
Switching Type	Sequential
TX/RX	RX/TX
Bandwidth MHz	6
Cross Talk dB	60
Detector Range m	15
Video Signal V, ohms	1 Vp-p, 75 Ohms
Termination	BNC
Physical Specifications	Dimensions mm: 44 x 432 x 165 Weight g: 2.6 kg
Electrical Specifications	Voltage: 240 V AC Power Consumption: 15 W
Environmental Specifications	Operating Temperature ^oC: 0 ~ 50
Analog Switcher Type	Matrix Switchers
Additional info	Multiple Language On-Screen Menu Driven Set-up. Time/Date/Text Insertion. Group Call-up for Cameras/Monitors. Programmable Camera Sequences incl. Preset Calls.
