Dahua DHI-LPH65/75/86/98-MC470-P 65/75/86/98'' DeepHub Pro Smart Interactive Whiteboard

Technical Specification

This product model is not available in this region

Dahua DHI-LPH65/75/86/98-MC470-P 65/75/86/98'' DeepHub Pro Smart Interactive Whiteboard

Features:

Make: Dahua Technology
Model code: DHI-LPH65/75/86/98-MC470-P
Monitor Type: LED
Effective Screen Size Inches: 65-inch; 75-inch; 86-inch; 98-
Color Type: Color

Additional info:

Equiped with Zero Air Gap technology, the 65, 75 and 86 inch 4K DLED display delivers clear images in sharp and vivid colors. The 98-inch display uses full lamination technology. Built-in AI 4K camera and 8 array microphone that produces excellent quality visual and audio communication. Wireless screen sharing from multiple devices with an intuitive, easy- to-use system. Ultra-smooth writing experience with handwriting recognition. Quick file sharing by scanning a QR code, with easy file encryption for added privacy and security. Optional OPS module, dual-system switchable. Fingerprint lock for protection of user information.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Dahua Technology
Manufacturer	Dahua Technology USA Inc.
Category	Video Surveillance>Security Monitors
Model code	DHI-LPH65/75/86/98-MC470-P
Monitor Type	LED
Effective Screen Size Inches	65-inch; 75-inch; 86-inch; 98-
Color Type	Color
Resolution	4K
Signal Mode	NTSC
Touchscreen	Yes
Housing Material	Metal casing
Built-in Speaker	Yes
Monitor Mount Type	Wall
Weight kg	65-inch: 40 kg , 75-inch: 54 kg , 86-inch: 67 kg , 98-inch: 91 kg
Scanning Frequency Hz	150 Hz ~ 20 kHz
Front Controls	1 × power button (right side), 1 × USB 3.0 (left side)
Environmental Specifications	Operating Temperature ^oC: 0 ~ 40 C (32 ~ 104 F) Operating Humidity %: 10 ~ 90
Electrical Specifications	Power Consumption: 65-inch: 200 W; 75-inch: 300 W; 86-inch: 400 W; 98-inch: 600 W Voltage: 100 ~ 240 V AC
Video Input	1 × HDMI IN
Additional info	Equiped with Zero Air Gap technology, the 65, 75 and 86 inch 4K DLED display delivers clear images in sharp and vivid colors. The 98-inch display uses full lamination technology. Built-in AI 4K camera and 8 array microphone that produces excellent quality visual and audio communication. Wireless screen sharing from multiple devices with an intuitive, easy- to-use system. Ultra-smooth writing experience with handwriting recognition. Quick file sharing by scanning a QR code, with easy file encryption for added privacy and security. Optional OPS module, dual-system switchable. Fingerprint lock for protection of user information.
