ComNet FVT1031M1 Video Transmitter/data Transceiver

Technical Specification

Features:
  • Make: ComNet
  • Model code: FVT1031M1
  • Data Transceiver: Yes
  • Transmitter Type: Yes
  • No of Fibres: 1
Read more
Additional info:

ComNet FVT1031M1 video transmitter/data transceiver supports simultaneous transmission of short-haul quality 10-bit digital video, bi-directional data and up-the-coax data over one multimode optical fiber. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces, and most major data protocols as well as up-the-coax data. The FVT1031M1 allows the user to choose bi-directional data or up-the-coax data through a switch on the unit.

Read more
Make ComNet
Manufacturer ComNet Europe Ltd.
Model code FVT1031M1
Data Transceiver Yes
Transmitter Type Yes
No of Fibres 1
No of Video Inputs 1
Bandwidth MHz 10
Physical Specifications Dimensions mm: 155 x 135 x 28
Weight g: 900
Environmental Specifications Operating Temperature oC: -40 ~ +75 C (-40 ~ +167 F)
Operating Humidity %: 0 ~ 95
Electrical Specifications Voltage: 8 ~ 15 V DC
Power Consumption: 2 W
Additional info ComNet FVT1031M1 video transmitter/data transceiver supports simultaneous transmission of short-haul quality 10-bit digital video, bi-directional data and up-the-coax data over one multimode optical fiber. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces, and most major data protocols as well as up-the-coax data. The FVT1031M1 allows the user to choose bi-directional data or up-the-coax data through a switch on the unit.
