VIVOTEK Video Surveillance Camera Lenses

According to IHS Market, it is estimated that there are over 60 million security cameras in the United States, and other reports say these cameras capture more than four billion hours of footage per week. Over the last decade, IP camera technology has dominated the conversation as it has provided users with a broad offering of enhanced image quality and features. With a large percentage of existing security systems relying on analog, many end users looking for high definition (HD) video quality have been forced to take on a complete system overhaul. Infrastructure Overhaul For HD Video To make the switch, customers would need to change everything, from cameras to hardware to wiring– not to mention the lengthy installation process that would ensue. IP cameras also require higher Internet speeds and more cloud space. Whether constrained by budget, bandwidth or storage, many end users have been unable to adopt this new video surveillance method.Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike Thanks to technological advancements within the security industry, HD over Coax offers a viable solution for integrators and end users alike. By utilising the current Coaxial cables, this offering yields high definition video, while requiring minimal infrastructure changes and is an optimal surveillance choice for security customers. Plus, with new advancements and updates being made frequently to this technology, there is a solution for every security need. The enhanced alternative of HD over Coax has been warmly welcomed in the security industry, thanks to its simple solutions and ever-evolving features. Many new analog HD cameras are “plug and play,” able to connect directly to existing Coaxial cables. This eliminates the need for a complete system change, creating cost-savings for the end user and an enhanced video quality offering. Easy Solutions For HD Video As a result, integrators can cost-effectively upgrade their customer’s surveillance solution while using their legacy infrastructure, making it an attractive option for end users and an easy sell for dealers. Latency in video is another common issue with network-based camera systems, where even the slightest delay in video surveillance can hinder security response HD over Coax cameras themselves are always expanding and evolving to meet a wide array of security needs. With the introduction of fisheye and multi-sensor cameras, users now have a multitude of coverage options, not to mention the introduction of 4K bringing resolution options to the same level as IP. Some newer technologies are even touting 4K cameras paired with 4K digital video recorders (DVRs) made specifically for analog systems. Longer cables grant transmission for up to 1600 feet, double the distance of standard analog solutions, and triple that of IP systems. This single cable is able to transmit both HD video and audio. Recently, broadcast quality audio over Coax has become available in limited models, a substantial improvement over older analog technology, which was unable to transmit audio. Stopping Video Delay Latency in video is another common issue with network-based camera systems. Even the slightest delay in video surveillance can hinder security response. IP cameras are forced to compress and packetize their video for transmission. The outcome of this is a reduced number of images per video, which in turn causes delay. HD over Coax on the other hand, delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity. Additionally, the point-to-point transmission delivers uncompressed video free of lag. Another touted benefit is that, unlike IP networked cameras, analog systems provide a more secure video transmission. With so much sensitive information housed on a businesses’ network, adding another point of network access through an IP camera can create concerns for cyber security risks. HD over Coax delivers an unlimited amount of HD images in real time, with smooth motion and impressive clarity Preventing Network Hacking With HD over Coax, the physical connections between the camera and DVR prevent network hacking. By keeping the video surveillance system offline, security professionals are able to direct their attention to the physical threats at hand, rather than having to focus on deterring cyber security risks. One of the primary difficulties of deploying HD video solutions is the fact that many older systems utilize a wide variety of HD standards and platforms. To make matters more complicated, after HD over Coax was brought to market, manufacturers raced to create their own version of this technology. Today, the most popular proprietary standards are HD-CVI, HD-TVI and AHD. However, integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible.Integrators and customers found that attempting to manage multiple HD technologies proved to be near impossible Diversifying Surveillance Through One DVR To combat these issues, manufacturers have introduced products with more flexibility to their portfolios. One example of this is the penta-brid DVR which grants the ability to seamlessly integrate multiple technologies deployed across one application. This means that systems with diverse camera brands and technologies, such as a mix of HD-CVI, HD-TVI, AHD, analog or IP, can be connected through one DVR. For many end users with legacy analog systems, penta-brid DVRs give them greater freedom to choose between a variety of solutions, rather than being limited to one option. With video resolution increasing, the space needed to store the footage is similarly rising. Penta-brid technology has been able to adapt to these evolving needs, giving users ample storage space to house the HD and 4K surveillance video with some of the newest models including H.265 compression.  HD Casino Surveillance Made Simple For casinos, HD images are critical for identifying unauthorized personnel and unlawful behaviours to create a safe environment for guests and staff While HD over Coax is beneficial to many end users and integrators, those in the casino and hospitality markets find it crucial. With a combination of high profile guests, large amounts of cash on hand, constant crowds and strict industry regulations, reliable video surveillance is a must. Deploying new IP systems comes at a stiff price. When looking to upgrade their video surveillance, casinos must also be mindful of the installation process. When moving to an IP-based system, ripping out old wires and replacing them with new is the standard practice. This practice can be both disruptive and costly, not to mention gaming regulations require casino activities be monitored at all times so a complete system shutdown would result in revenue loss. This cost can be hard to justify, especially when the current legacy analog system remains in working condition with only the lower image resolution to date it. For these scenarios, the most cost-effective option is to leverage the legacy infrastructure, replace the existing cameras with new devices, and reap the benefits that HD video has to offer without any lapse in security. For casinos, HD images are critical for identifying unauthorized personnel and unlawful behaviours to create a safe environment for guests and staff. HD over Coax cameras now offer the same resolution as IP cameras with a plug and play approach, that cuts down on expense without sacrificing quality. For businesses and applications that are unable to adopt IP technology, whether it be cost or time prohibitive, HD over Coax now features most of the same benefits IP has to offer without breaking the bank. By providing clear images in real time, maximizing existing infrastructure, and affording cyber security benefits, HD over Coax provides an attractive solution for many end users and integrators.

When people think of control rooms, images from James Bond movies or intense action stories come to mind. What they fail to realise is the incredible level of ergonomics, technology, precision and craftsmanship required to create a top-notch command and control room. “These are rooms of complex functionalities, where hundreds of elements must be integrated and function in sync,” says Jim Coleman, National Sales Manager, AFC Industries. Professional teams from several different industries must coordinate every single detail in order to ensure that functionality occurs each and every time. Reconfigurable Furniture For Control Rooms AFC Industries is one company that specialises in equipping control rooms for security and other applications. AFC Industries was established in 1994 as a family-owned business that focuses on the design and construction of ergonomic products. Their height-adjustable units guarantee the right height for standing desks as well as traditional sitting levels. The company produces an array of Command and Control ergonomic security consoles and mounting solutions. Modular racking systems facilitate efficient storage of electronic and audio-visual equipment. As technology changes, older traditional consoles are no longer a necessity. Many organizations instead are choosing to use lighter, less costly, reconfigurable furniture that allows more flexibility. Command Centers need to be able to reconfigure the space at will. Because most systems are housed in secure data centers, users should be able to quickly move their positions by relocating their workstations, utilising different network connections. Simple control room features, like those addressing lighting or operator comfort, can make the difference in a correct or incorrect decision during a crisis Emergency Operations Centers A positive trend driving the market for control rooms is an increase in emergency operations centers (EOCs), says Randy Smith, President of Winsted. “Everybody is concerned about what happens in an emergency,” says Smith, and the centers are popping up as a tool for emergency preparedness. It’s another environment where sit-stand work stations are the rule. Winsted’s product lines include stock modular and customized elements in good-better-best categories – from basic to lots of “bells and whistles;” jobs can be configured from modular elements or customized as needed. Customized Control Rooms For Seamless Operation There is a lot at stake in control room design: Lives can depend on how effectively a control room functions in an emergency. Control rooms should seamlessly accommodate both everyday occurrences and crisis situations, says Matko Papic, Chief Technology Officer of Evans Consoles. Better-operating control rooms can increase efficiency and reduce and/or mitigate risk. Simple control room features, like those addressing lighting or operator comfort, can make the difference in a correct or incorrect decision during a crisis. Addressing operator comfort can reduce the possibility of workers’ compensation claims. End users are seeing multiple benefits of creating a better operating environment, better sightlines, more comfort and attention to ergonomics. As a fully integrated control room solutions provider, Evans Consoles approaches the needs of a control room environment beginning in the conceptual/operational planning stage. They consider broad issues such as how information will be processed, the interface between technology and operators, and the cognitive and physical interactions of operators – understanding that these factors drive the layout and function of control rooms. After analyzing tasks to be performed in the environment, Evans lays out the consoles to meet those needs. Rather than a predesigned solution, each installation is tailored around a specific application. Read part 2 of our Control Rooms series here

Many end-users shell out the cash to acquire the newest high-end devices, plug in, and expect to be wowed A well-developed surveillance system can give a single security guard the power to see what otherwise might take a hundred pairs of eyes to see. But what happens when all the components are all connected and powered up, and the resulting image on the screen is, well, indiscernible, or, at the very least, terribly pixelated? Many end-users shell out the cash to acquire the newest high-end devices, plug in, and expect to be wowed. Often enough, however, what they see on the screen is not what they were expecting – and they wonder what they just paid for. In a good high-definition system, what factors actually create the best image quality? With so many variables involved, from the camera’s lens to the imaging algorithms to the monitor resolution – just to name the obvious ones – how do system integrators achieve the best on-screen images?   The Lens The first component to handle light from an object, this may be the one most taken for granted in cameras of any sort. (Just try scratching or cracking one and you’ll agree.) In the days of analog cameras, it seemed that any old lens would do just fine. However, as the technology inside cameras evolved and more powerful sensors (more pixels) became available, engineers and programmers demanded more from lenses. Moreover, intelligent video content analyses would be impossible without high-accuracy lenses.In what way do lenses impact the image quality? The key factor here is light transmission. The quality of light passing through the lens itself will forever be critical to the quality of image reproduced. A lens made using ultra-precision molding aspherical technology achieves more accurate color, better light, and clearer images. Multilayer broadband anti-reflection coating further maximises a lens's light transmission while minimizing the residual reflection of light on the surface of each optical lens. Variables involved include the camera’s lens, the imaging algorithms and the monitor resolution When it comes to fabricating a megapixel lens that hits the mark, the materials used and the processes by which lenses are produced are the two most critical criteria. The materials most often used to create lenses are glass and specialized plastics. An HD lens made of ultra-low-dispersion optical glass – which, by using dispersion characteristics that are different from those of conventional optical glass – will deliver better HD performance. Machine-automated lens production using specialized plastics results in high output for camera producers, and the lenses produced are more uniform in design and quality. For an HD vari-focal lens, its image quality depends largely on the precision of the cam. The cam rotates to drive the zoom and focus lens groups forward and backward for a smooth continuity of focal length and adjustment of the focal point. A lack of precision with the cam inevitably causes an offset or tilt of the lens' optical axis during zooming and focusing, leading to a serious loss of image quality. Lens production is a delicate balancing act. The slightest errors or imperfections will be very noticeable when tested Lens production is a delicate balancing act. The slightest errors or imperfections will be very noticeable when tested. The features of a lens that affect image resolution, clarity, and contrast must be perfect. Achieving uniformity of image resolution at the center and the edges of a lens requires high-precision machinery. And once a lens has been properly crafted, the assembly of the camera, the lens housing materials, and the alignment of the optical axis demand utmost accuracy. To put it mildly, quality control must be rigorous. Image Signal Processing As light passes through the lens, the sensor captures it and converts it to data. Raw RGB data is transmitted by the camera sensor and undergoes Image Signal Processing (ISP) such as noise reduction, white balance, WDR, curve correction and color correction, etc. The data is then transformed to true colors for each pixel point, for people to see images that look “normal” to the human eye. It is the Image Signal Processing that defines the final image quality on the screen. Collecting data in different conditions is vital, for instance, outdoor data should be analyzed with natural light on days with sun, overcast, rain, and fog, at dawn, at dusk, and so on. Similarly, when using cameras equipped with infrared sensors, testing the IR light signals in various conditions is necessary as well.  Actual image performance depends upon variables such as low light illumination, signal to noise ratio, dynamic range of light, and more. ISP algorithms aim at increasing the signal data and decreasing noise. Cameras with Wide Dynamic Range (WDR) will yield improved video imaging with both background and foreground objects in high contrast or high-backlight environments, maximising the amount of detail in brighter and darker areas in one field-of-view. In scenes with low contrast and low light, the sensors deliver digital image signals and at the same time send some amount of digital noise that directly hinders image clarity. Three-dimensional digital noise reduction (3D DNR) removes unwanted artifacts from an image, reducing graininess. Where cloudy weather poses a challenge, auto-defogging technology helps to identify the density of fog or rain with gray-white color ratio analysis, and imbues images with true color reproduction. Ramping up the megapixels and frame rates yields great video, but also results in more bandwidth used and more storage occupied Matching Megapixels To Image Quality When the factors mentioned above line up well, correlating cameras and monitors creates the best viewing experience. When a high definition camera is in place, a monitor with a high resolution will display images much more clearly. But if the monitor’s resolution is low, it will not deliver the high-quality images expected – or possible – from that HD camera. For an 8 MP camera, for instance, users do best to apply monitors with 4K × 2K resolution. Though common sense, this deserves to be mentioned because users might decide to upgrade their systems with 4K monitors, but with perhaps 1.3 MP cameras installed. In such a scenario, there’s no guarantee the on-screen image quality will automatically improve. Managing Data And Bandwidth In terms of a complete, high definition surveillance system, when the right factors come together and the calibrations are set, image quality – even in a standard HD 1080p setup – can be extremely good. The final piece of the puzzle is managing the data. Ramping up the megapixels and frame rates yields great video, but also results in more bandwidth used and more storage occupied. Squeezing bandwidth threatens image quality and clarity, but keeping ample room for signal transmission and storage will eventually increase the overall cost for customers. Is it possible for integrators to optimize their customer’s system and, at the same time, stay within budget constraints? Luckily, it can be done. Squeezing bandwidth threatens image quality and clarity, but keeping ample room for signal transmission and storage increases the overall cost for customers To do this, a more efficient video encoding solution would allow an improvement in compression efficiency of 40–50% over H.264. Improvements to algorithms that are adaptive to a particular scene give users control over bitrate. Another option would be to start recording video only when an event triggers an alarm, since most security guards are primarily concerned with moving objects rather than a scene’s generally stagnant background. This intelligently helps optimize bandwidth and storage consumption. Another method is to use a single panoramic or fisheye camera in place of several HD cameras for coverage – the reduced number of security devices will reduce bandwidth demands and the rate of storage consumption as well. Getting The Best Image Quality Now let’s put this all together. Naturally, integrators and users will refer to their product specs to understand features and functions, fine-tuning each component for best results. Also, as suggested above, users should select an HD camera comprehensively in terms of lens performance, pixels, image quality, and overall system compatibility and performance. Next, matching the backend device and management platform should be carefully considered in a complete security system. Installing equipment that has been engineered for a given scene is a must, along with strategising how to get the most coverage out of the lowest number of cameras. Finally, product quality, warranty, price, and on-going customer service are all important factors that customers should take into account as well.

In today’s technology-driven markets, a platform is a business model that connects producers and consumers in an interactive ecosystem. Some examples of platforms are Uber and Airbnb, which have disrupted and transformed traditional markets. Isn’t it time to deploy the platform model in the physical security industry? That’s the goal of the Open Security & Safety Alliance (OSSA), a non-profit organization. Interactions And Exchange The book ‘Platform Revolution’ defines a platform as ‘a business based on enabling value-creating interactions between external producers and consumers.’ The description continues: ‘The platform provides an open, participatory infrastructure for these interactions and sets governance conditions for them. The platform’s overarching purpose is to consummate matches among users and facilitate the exchange of goods, services, or social currency, thereby enabling value creation for all participants.’ Platform For Security And Safety Solutions OSSA’s plan is to build a common standardized platform for security and safety solutions. Founding members are Bosch Building Technologies, Hanwha Techwin, Milestone Systems, Pelco and VIVOTEK. Anyone can join the alliance, which is growing rapidly and gaining traction as the Internet of Things (IoT) expands. OSSA’s plan is to build a common standardised platform for security and safety solutions OSSA members could be found throughout the recent ISC West show in Las Vegas, and a social event after hours at the show brought them together and set the tone for development to come. A Technology Stack “We want to create an ecosystem, define a common market approach and open new market opportunities,” says Johan Jubbega, OSSA President. “We want to go from a product business to a platform business. It’s better for us and better for the end-users.” OSSA seeks to develop a specification for a common Technology Stack to cater to innovation and reduce fragmentation within the security and safety market, according to OSSA. Its mission is complementary to organizations like ONVIF. Video Information And Low Friction The video surveillance industry creates vast amounts of information in the form of video, but typically less than 1 percent of that data is used by today’s video surveillance systems – think about that one or two frames of video among thousands that might be used to solve a crime, for example. The rest of the data remains unused, and yet the potential value of the data is huge. OSSA seeks to create a platform to leverage the value of the data. “If we don’t unlock that value in our industry, someone will do it for us,” says Jubbega. OSSA is developing a vendor-agnostic operating system that simplifies low-level device integration and standardizes elements such as cybersecurity and security update patches Among the important elements in developing the platform are to create a level of trust among all the stakeholders involved, and to lower the ‘friction’ involved in participating in the platform. “We want to make it easy and fun to do business with anyone who joins the platform,” says Jubbega. “By taking away the friction, we will create scalability.” System-On-Chip Development of customisable system-on-chip (SoC) components in today’s video cameras provide the capacity to host a variety of ‘apps’ to expand system functionality and leverage the value of data. OSSA is developing a vendor-agnostic operating system that simplifies low-level device integration and standardizes elements such as cybersecurity and security update patches. Building on top of that operating system, vendors can create new levels of differentiation. “Our purpose is to start from a common business model to spur innovation and add value for users,” according to OSSA. Cybersecurity And Data Protection SAST is creating the operating system and setting up the IoT infrastructure to make apps available Simply speaking, app developers can use the standard operating system to build new functionalities that can easily be ‘loaded’ on cameras and sold in an ‘app store’ scenario. Security and Safety Things (SAST), a Bosch startup and member of OSSA, is creating the operating system and setting up the IoT infrastructure to make the apps available. Development of these elements is happening concurrently with the evolution of OSSA. “We offer you an opportunity to come with us on this journey,” Jubbega told attendees at the ISC West social event. “We want to have a common approach to tackling cybersecurity and data protection – to raise the bar in the industry. You can still differentiate, but from a higher base.” OSSA members who exhibited at ISC West included Anixter Inc., Bosch Building Technologies, Hanwha Techwin, Milestone Systems, NetApp Inc., Pelco, SAST, Socionext Inc., United Technologies and VIVOTEK Inc.

Parekh Integrated Services Pvt. Ltd (PISPL) is in the business of providing high-quality logistics services that give customers a competitive advantage in the Indian market. Established in 1981, PISPL is a one-stop shop logistics and supply chain service provider in India offering storage and distribution services, freight forwarding, transportation, information technology and cold chain management solutions along with other value added services to multiple industry verticals. Video Surveillance Systems Parekh Integrated Services Pvt. Ltd (PISPL) has established their operation with more than 1,500 warehouses and distribution setups to cover all the major cities in India for their services. With this expansion, IT infrastructure equipment was procured, including IP video surveillance systems of different reputed brands from different vendors. Cost of operation has also gone up due to technical expertise required for each individual system Over a period, it was becoming costly and difficult to manage different brands procured separately at different locations. Cost of operation has also gone up due to technical expertise required for each individual system. PISPL was looking for a centralized solution, which can work with different reputed brands as well as give them a common control of all the video surveillance systems to reduce the technical manpower cost for different systems. Occupancy Control System Due to low bandwidth at some of the remote locations, PISPL were not able to secure video evidence at a central location. It was required for any kind of post analysis or dispute resolution. PISPL were looking for an occupancy control system in each warehouse/storage area to manage and control the worker's presence in sensitive areas. It was getting difficult to do it manually at each location with the increase in number of employees over the last few years. Matrix provided video management software (VMS) as a centralized platform to monitor and manage all the cameras from a central location on a single platform. It worked as a common platform for all the surveillance cameras from different brands, which leads to reduction in operation cost. Matrix VMS supports all the camera models of major brands including ACTI, Samsung, SONY, Mobotix, Panasonic, Vivotek, etc., along with ONVIF protocol. Crowd Management Feature PISPL enabled the centralized schedule backup at an even lower bandwidth from all locations to the central location Using Matrix VMS Solution, PISPL enabled the centralized schedule backup at an even lower bandwidth from all locations to the central location. This made it easy to go through the video evidence at a central location and resolve the issue in short time. Another issue of maintaining occupancy a certain limit in each zone was addressed by the Matrix VMS crowd management feature. All the entry/exit points were covered with a camera to count number of heads passing through the points. From central control room, using Matrix smart client, security can monitor the total occupancy of an area and instruct the team accordingly. Thus, it provides a common platform to connect multi-brand cameras, secure video evidence at central location and control zonal occupancy, which were the major challenges. Control Zone Occupancy Why did PISPL choose Matrix? Matrix VMS architecture supports centralized / decentralized monitoring and management Matrix VMS interoperable with most of the reputed brands Possibility of scheduled backup at central location even at lower bandwidth People counting feature to control zone occupancy Benefits: Centralized control and management Ease of use Secure evidence Improve productivity Products: SATATYA SAMAS GE PLATFORM - VMS Platform with 50 camera licenses SATATYA SAMAS CAM20 – 20 camera additional licenses SATATYA SAMAS CROWD - 20 camera additional licenses management cam5

VIVOTEK, globally renowned IP surveillance solutions provider, has announced the end-to-end comprehensive protection in its Cybersecurity Management Solution under the strategy of the “Security within Security” campaign. The solution provides a robust shield that starts from the front-end network camera, to the network video recorder, and to the back-end video management software. This solution will be displayed in VIVOTEK’s booth (#12089) at ISC West 2019, taking place from April 10 to 12 at the Sands Expo, Las Vegas, United States. VIVOTEK – Trend Micro Collaboration Built in collaboration with Trend Micro, globally renowned cybersecurity solutions firm, VIVOTEK’s network cameras and video recorders are embedded with Trend Micro’s anti-intrusion software with multi-layer protection, including brute force attack detection, intrusion detection & prevention, and instant damage control. Users can obtain the following cybersecurity management features with the latest firmware update releases, available by the end of April. The advanced management in its self-developed video management software, VAST 2 includes Instant Alert Notifications, allowing users to receive notifications either automatically or manually, and real-time Cyber Risk Dashboard to easily identify common types of cyber-attacks. Last but not the least, users can take a further step to filter attack logs through different criteria, making it quicker to find abnormal events in a large number of records. Cybersecurity Management Solution Shengfu Cheng, Director of VIVOTEK Marketing and Product Development Division, commented, “To address the rising threat to cybersecurity, VIVOTEK puts enterprise power and resources in the hands of Cybersecurity Management Solution. This solution allows users to respond faster to threats and minimize cyber risks in IP video surveillance networks. We will continue working to provide our valued customers with reliable products under cybersecurity protection.”
