Verkada BP32-HW-NA Wireless Alarm Panel
Technical Specification
- Make: Verkada
- Model code: BP32-HW-NA
- Control Panels & Accessories: Yes
- Wireless: Yes
- Tamper: Yes
The BP32 Wireless Alarm Panel acts as the central brain of a Verkada wireless alarm system. Powered by a single PoE cable and small enough to fit discreetly in tight spaces, the BP32 is easy to install in any environment. The panel alone supports up to 160 wireless sensors via its built-in VLink hub, with unlimited expansion through WH52 hubs, WH32 repeaters, and BK22 keypads.
Read more| Make | Verkada |
|---|---|
| Manufacturer | Verkada Inc. |
| Category | Intruder Alarms>Intruder alarm system control panels & accessories |
| Model code | BP32-HW-NA |
| Control Panels & Accessories | Yes |
| Wireless | Yes |
| Tamper | Yes |
| Keypad Operated | Yes |
| Mount Type | Wall, Ceiling |
| Physical Specifications | Dimensions mm: 343 x 191 x 44 |
| Environmental Specifications | Operating Temp oC: 0 ~ 50 C (32 ~ 122 F) |
Product description
BP32 Wireless Alarm Panel
The Verkada BP32 Wireless Alarm Panel is a robust solution for managing a comprehensive security system. It serves as the core of a wireless alarm setup, powered conveniently by a single PoE cable, which enables easy installation even in confined spaces. The BP32, featuring an integrated VLink hub, supports up to 160 wireless sensors, and offers unlimited expansion possibilities through the addition of WH52 hubs, WH32 repeaters, and BK22 keypads.
Key Features
- Complete Site Coverage: Built-in VLink hub accommodates up to 160 wireless sensors. Connect unlimited BK22 keypads and WH52 hubs for extended network.
- Cloud-Managed: Seamlessly administrate all devices via Verkada's Command application, with minute-level automatic health checks and firmware updates ensuring optimal performance and security.
- Highly Available: Operates offline with local alarm and access control for reliability despite network disruptions, bolstered by a built-in LTE backup and a 30-hour backup battery.
Compact Design
The BP32's small, unobtrusive form factor allows it to fit discreetly into any environment, making it ideal for varied installation settings.
Ideal Use Cases
Designed for reliable operation in environments prone to network instability, the BP32 is perfect for facilities requiring robust security and seamless management across diverse locations. Its capability to integrate with other Verkada products enhances operational efficiency in multi-site organisations.
Technical Specifications
- Power Consumption: 3.1W standby, 24.5W max
- Network: 100/1000 Mbps RJ45 port, CAT 4 LTE modem
- Backup Battery: 57.6 Wh, up to 30-hour uptime
- Operating Temperature: 0 to 50°C
The BP32 Wireless Alarm Panel stands out as a versatile and reliable component for enhancing site security, combining advanced features with user-friendly cloud management.
