Verint New Single And Dual Port Encoders Featuring Triple H.264 Streams At D1/25fps
Product Profile
Built on a decade of deploying over one million ports, the Nextiva S1800e single- and dual-port encoders are ideal for one- or two-camera implementations in distributed networks, in which excellent video quality, a compact design, and storage and bandwidth optimisation are key. The S1800e single- and dual-port encoders couple superior video resolution up to three H.264 video streams D1/25fps and storage on the edge-a failover mechanism that ensures video is recorded in case connection with the management software is lost.
Model: S1801e, 1-port video encoder, triple H.264 streams@D1/25fps + MJPEG-4 stream@4CIF/25fps, storage on the edge functionality (SDHC MicroSD card, not included), Energy Star power supply included
Model: S1801e-PoE, 1-port video encoder with PoE support (PoE injector not incl.) triple H.264 streams@D1/25fps + MJPEG-4 stream@4CIF/25fps, storage on the edge functionality (SDHC MicroSD card, not included), Energy Star power supply included
Model: S1802e, 2-ports video encoder, triple H.264 streams@D1/25fps + MJPEG-4 stream@4CIF/25fps, storage on the edge functionality (SDHC MicroSD card, not included), Energy Star power supply included.
Technical Specification
| Make | Verint |
|---|---|
| Manufacturer | Verint Systems |
| Category | Video Surveillance>Video servers (IP transmission) |
| Model code | Nextiva S1801e-R |
| Video Inputs | 1 |
| Other Inputs | 2 |
| Compression Type | H.264, MPEG-4 |
| Network Protocols | RTP/IP, UDP/IP, TCP/IP, or multicast IP |
| Interface | RJ-45, Ethernet 10/100 Base-T |
| Image per second (IPS) | 30 fps |
| Physical Specifications |
Dimensions mm: 106 x 90 x 42 Weight g: 260 |
| Electrical Specifications |
Power Consumption: 4 W Voltage: 12 V DC |
| Environmental Specifications | Operating Temperature oC: 0 ~ 50 |
See comparison of Verint Nextiva S1801e-R with similar Verint Video servers (IP transmission)
