Compatible with most Aiphone surface mount door stations Attachment holes for different standard mounting boxes, including 1- and 2-gang Mild steel front box, stainless steel back plate Conduit knockout at the base

An interface between the door release contact on the Aiphone master station or CEU and the actual release mechanism Form C relay for 18-24V DC intercom systems Both normally open and normally closed output options

Allows an external device to be triggered when the intercom is called External device will be activated when the door station calls in

An adaptor for the JO Series video intercom system Allows two video door stations to be used in a standard or app-enabled system The adaptor has inputs for two JO Series video door stations and outputs to control door release for each of those door stations When a visitor calls at the door station, his image will be displayed on the inside station(s) The person at the JO-1MDW, JO-1MD, or JO-1FD, answers the call, and if they decide to grant the visitor entry, pushes the door release button to activate the electric lock only at the associated door If one door station is in use, the call button on the other door station will not activate a call-in

PoE compliant 20 Form C relays Relay rating (24V AC/DC 500mA) Max of 16 adaptors per building

Works with existing 2-conductor wire Supplies PoE to stations Rack mount receiver LED status indicators

Works with existing 2-conductor wire Supplies PoE to stations LED status indicators

 A UL listed 12V DC, 5A plug-in power supply Used to power ACS-2DR two-door access control starter kit and ACS-IO I/O starter kit

Works with existing 2-conductor wire Supplies PoE to stations LED status indicators

Vandal-resistant with 16-gauge stainless steel construction Flexible design can be mounted to either side of the door 1-gang hole pattern allows for easy installation

Flexible design can overhang mullion on either side of the door Wire cutouts allow for installation when there is an external conduit Clearance for Cat-5/6 cables prevents overbending

Weather resistant Vandal-resistant Inside space for cabling Mounts to 1-gang box or ring Can mount on a flat wall

Allows desk mounting of master and/or handset station Station is propped up for easier viewing Pre-drilled mounting holes Constructed with sturdy ABS plastic Adjustable to 45° or 60° angles

A 1-gang mounting plate  Used with the JO-DV, JP-DV, and JV-DV door stations

Provides a better viewing angle for the camera Compatible with Aiphone 1-gang surface mount door stations Angles 1-gang door stations outward by 30° Can mount to either right or left of door Hinged cover for mounting door station

Steel construction Mounts to a door mullion of a glass entry Weather resistant for outdoor use Mounts door station at 45° angle Mounts any 1-gang surface mount Aiphone Audio-only or Audio Video Door Station

Vandal resistant stainless steel Mounts Intercom and Access Control device together Any 1-gang Audio-only or Audio Video Door Station can be used Blank faceplate allows wide range of mounting options Hooded covering to protect units from direct exposure to weather Tamper resistant mounting hardware

802.3af PoE Four contact inputs Ten Form C relay outputs 24V AC/DC 500mA relay contact rating Mountable to a 170mm DIN rail or directly to a wall

Works with existing 2-conductor wire Supplies PoE to stations Rack mount receiver LED status indicators

Supports up to 500 registered SIP devices and up to 75 concurrent calls Dual Gigabit network ports with integrated PoE+ Built-in call recording server; recordings accessed via web interface Built-in call detail records for tracking phone usage Supports any SIP video endpoint Supports voice mail Supports call queue for call volume management

Steel construction Six conduit knockouts

Provides a 24V DC output to power the strobe light in Aiphone’s wall boxes and towers The IX Series emergency stations have a secondary PoE output (passthrough) that can be used to connect to this splitter The PoE passthrough will only be usable if the IX Series station is connected and powered via a PoE+ switch

Provides a normally open dry contact closure upon call-in at a tenant station Also provides a contact to turn on external light at entrance station when calling tenant station

Weather resistant Vandal-resistant Inside space for cabling Mounts to flat wall surface Opening at bottom for drainage

Weather resistant Includes the SBX 2G/A surface mount box and PS POE splitter to power the sensor Powered from either a PoE network drop or from the LAN 2 output on an IX Series door station (requires PoE+ switch) Form C dry contact output can be connected to the trigger input of an IX Series door station Allows visitors to place a call without touching the call button on the door station Sensor is illuminated in blue while in standby and turns green when activated

Stainless steel construction One conduit knockout on the bottom side One or two-gang mounting hole pattern Built-in rain hood

PoE (IEEE 802.3af class 0) DIN rail mountable Eight simultaneous calls per adaptor Supports up to 9,999 IXG mobile apps Optional 4G LTE data connection Allows telephone calls from door and entrance stations

PoE compliant 20 Form C relays Relay rating (24V AC/DC, 500mA) 16 adaptors per building max.
