SALTO CU50ENSVN On-line IP Door Controller With Two Wall Reader Connections

Technical Specification

Features:

Make: SALTO
Model code: CU50ENSVN
Series: XS4 Series
Controller Type: Standalone/Networkable
Max No. of Doors per Controller: 1

Additional info:

The SALTO CU50ENSVN is an on-line door controller that can have 1 or 2 wall readers connected, has 2 control relay outputs and has SALTO Virtual Network (SVN) capabilities. Cards are automatically updated with the latest changes in the access plan, it records the user audit into the PC and provides advanced information on battery status. It also continually updates the canceled ID carrier black list simply by using the cards on the network, distributing the latest access information throughout the building via the off-line stand alone locks.

Contact manufacturer Contact manufacturer

Make	SALTO
Manufacturer	SALTO Systems
Model code	CU50ENSVN
Series	XS4 Series
Controller Type	Standalone/Networkable
Max No. of Doors per Controller	1
No of Cardholders	64,000
Offline Capabilities	Yes
Networkable	Yes
Onboard No/Type of Inputs / Outputs	2 relay outputs
Electrical Specifications	Voltage: 12 V DC
Environmental Specifications	Operating Temp ^oC: -20 ~ +80
Additional info	The SALTO CU50ENSVN is an on-line door controller that can have 1 or 2 wall readers connected, has 2 control relay outputs and has SALTO Virtual Network (SVN) capabilities. Cards are automatically updated with the latest changes in the access plan, it records the user audit into the PC and provides advanced information on battery status. It also continually updates the canceled ID carrier black list simply by using the cards on the network, distributing the latest access information throughout the building via the off-line stand alone locks.
