SALTO CU50ENSVN On-line IP Door Controller With Two Wall Reader Connections

Technical Specification

Features:
  • Make: SALTO
  • Model code: CU50ENSVN
  • Series: XS4 Series
  • Controller Type: Standalone/Networkable
  • Max No. of Doors per Controller: 1
Read more
Additional info:

The SALTO CU50ENSVN is an on-line door controller that can have 1 or 2 wall readers connected, has 2 control relay outputs and has SALTO Virtual Network (SVN) capabilities. Cards are automatically updated with the latest changes in the access plan, it records the user audit into the PC and provides advanced information on battery status. It also continually updates the canceled ID carrier black list simply by using the cards on the network, distributing the latest access information throughout the building via the off-line stand alone locks.

Read more
Make SALTO
Manufacturer SALTO Systems
Model code CU50ENSVN
Series XS4 Series
Controller Type Standalone/Networkable
Max No. of Doors per Controller 1
No of Cardholders 64,000
Offline Capabilities Yes
Networkable Yes
Onboard No/Type of Inputs / Outputs 2 relay outputs
Electrical Specifications Voltage: 12 V DC
Environmental Specifications Operating Temp oC: -20 ~ +80
Additional info

The SALTO CU50ENSVN is an on-line door controller that can have 1 or 2 wall readers connected, has 2 control relay outputs and has SALTO Virtual Network (SVN) capabilities. Cards are automatically updated with the latest changes in the access plan, it records the user audit into the PC and provides advanced information on battery status. It also continually updates the canceled ID carrier black list simply by using the cards on the network, distributing the latest access information throughout the building via the off-line stand alone locks.
