Pelco ES5230-02N 2 Megapixel IP Positioning System

Technical Specification

Features:

Make: Pelco
Model code: ES5230-02N
Series: Esprit Series
Chip Inch Size: 1/3
Color Type: Color / Monochrome

Additional info:

Pelco ES5230-02N is part of ES5230 series of IP positioning systems. It supports high-profile H.264 compression as well as features open architecture connectivity for third-party software recording solutions allowing integration into virtually any IP-based HD system.

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	Pelco
Manufacturer	Pelco, Inc
Category	Video Surveillance>IP Dome cameras
Model code	ES5230-02N
Series	Esprit Series
Chip Inch Size	1/3
Color Type	Color / Monochrome
Resolution TVL	2 MP
HD	Yes
Megapixel	Yes
Sensitivity lux	0.07
Pan Speed ^o/ sec	0.1 ~ 40
Indoor/Outdoor	Indoor/Outdoor
Digital (DSP)	Yes
Tilt Speed ^o/ sec	30
Mount Type	Pedestal
Electrical Specifications	Voltage: 24 V AC
Presets	256
Compression	H.264
Back Light Compensation	Yes
Auto Gain Control	Yes
Zoom Ratio	x12
Network Properties	Network Protocols: TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, IPv6*, SNMP v2c/v3, QoS, HTTP, HTTPS, LDAP (client), SSH, SSL, SMTP, FTP
Physical Specifications	Weight g: 9,000
Environmental Specifications	Operating Temp ^oC: -40 ~ +50 C (-50 ~ +122 F)
System Requirements	Web Browser: Microsoft Internet Explorer or Mozilla Firefox
Additional info	Pelco ES5230-02N is part of ES5230 series of IP positioning systems. It supports high-profile H.264 compression as well as features open architecture connectivity for third-party software recording solutions allowing integration into virtually any IP-based HD system.
