NAPCO C100ST Adaptive® Dual Microwave/PIR Detector
Technical Specification
- Make: NAPCO
- Model code: C100ST
- PIR Detectors: Yes
- Dual/ Quad Technology: Dual Technology Detectors
- Coverage/ Range m: 9.1 x 10.6 m
Broad range and wide angle coverage suitable for most residential & commercial installations worldwide. Patented Adaptive® technology continuously monitors and dynamically self-adjusts the sensor to its environment. Smart microprocessor-based false alarm discrimination. 12 automatically selected, dynamic Adaptive® detection modes for optimal “intruder catch” and stability. Dual technology microwave and PIR signal verification. Active, automatic self-testing of all key components and circuits. Optimized field-of-view with custom-engineered aspheric optics. Critical Range Control. Fast, flexible mounting. True Automatic Temperature Compensation.
Read more| Make | NAPCO |
|---|---|
| Manufacturer | NAPCO Security Systems Inc |
| Category | Intruder Alarms>Intruder detectors |
| Model code | C100ST |
| PIR Detectors | Yes |
| Dual/ Quad Technology | Dual Technology Detectors |
| Coverage/ Range m | 9.1 x 10.6 m |
| Microwave | Yes |
| Pet Tolerance | Yes |
| Temperature Compensation | Yes |
| Mount Type | Wall / Corner mount |
| White Light Filter | Yes |
| Electrical Specifications | Power Supply: 10.6 ~ 16 V DC |
| Physical Specifications | Dimensions mm: 84 x 64 x 48 |
| Environmental Specifications | Operating Temp oC: -10 ~ +50 C (14 ~ 122 F) |
Product description
The NAPCO C100ST Adaptive® Dual Microwave/PIR Detector revolutionizes security monitoring with its intelligent design, providing unparalleled false alarm immunity and reliability. Engineered for both residential and commercial installations, this sensor boasts a broad range, covering 30 x 35 feet (9.1 x 10.6 meters) with a standard wide-angle lens. Its patented Adaptive® technology dynamically adjusts sensitivity to environmental changes, ensuring optimal intruder detection and minimizing false alarms caused by pets, fans, or changing light conditions.
Exceptional Features
- Adaptive® technology continuously refines sensor sensitivity to maintain peak performance in any environment.
- Microprocessor-based false alarm discrimination systematically analyzes signals to differentiate between real threats and common disturbances.
- Dual technology integration—utilizing both microwave and PIR signals—ensures accurate alarm verification.
- Automatic self-testing mechanisms verify operational integrity every 11–16 hours, preventing any compromise in security.
- Customizable range for targeted protection with a fine-tune adjustable potentiometer.
- Superior protection against RFI, EFI, and lightning with enhanced shielding.
- Additional field-changeable lenses available for customized applications.
Ideal Use Cases
The NAPCO C100ST detector is perfectly suited for environments where swift intruder detection is critical, without the nuisance of false alarms. It's an ideal choice for offices, retail spaces, and residential properties, offering reliable performance in settings with varying environmental challenges.
