Hikvision DS-K6B630TX: Smart Pro Swing Barrier for Modern Access Control
Technical Specification
- Make: Hikvision
- Model code: DS-K6B630TX
- Type of barrier: Swing Barrier
- Power Consumption: Standby: 70 W ; Working: 180 W ; Peak: 280 W
- Voltage: 100 ~ 240 V AC
Aluminum alloy material with optional color (default rose gold). 6.95-inch display screen and built-in face recognition module. Supports built-in palm print & palm vein module and QR recognition module (optional). Support PC & Mobile web configuration and self-diagnosis for maintenance. AP mode function for mobile phones (Android) to access more easily by a simple touch via NFC tag. Fire linkage: When the fire signal is triggered, the barrier will be open automatically for emergency evacuation. 12pcs of dToF sensors.
Read more| Make | Hikvision |
|---|---|
| Manufacturer | Hikvision USA Inc. |
| Category | Access Control>Barriers |
| Model code | DS-K6B630TX |
| Type of barrier | Swing Barrier |
| Power Consumption | Standby: 70 W ; Working: 180 W ; Peak: 280 W |
| Voltage | 100 ~ 240 V AC |
| Dimension | 1550 x 120 x 1002 |
| Construction | Acrylic glass (Barrier) ; Aluminum alloy (Pedestal) |
Product description
Hikvision DS-K6B630TX Prime Pass Swing Barriers
Enhance security operations with the Hikvision DS-K6B630TX Prime Pass Swing Barriers, designed using high-quality aluminum alloy with optional custom color finishes including default rose gold. Equipped with advanced technology, this barrier system offers a seamless integration of security features with aesthetics.
Distinctive Features
- 6.95-inch IPS display screen with a built-in face recognition module for enhanced identification accuracy.
- Optional palm print and palm vein recognition, along with QR code scanning, offer multifactor authentication.
- Automatic emergency response with fire linkage functionality for rapid evacuation during emergencies.
- Featuring 12 dToF sensors, ensuring precise and reliable operational performance.
Technical Specifications
- Servo motor ensures smooth operation and longevity with an MCBF of ≥ 11 million cycles.
- Supports communication via wired network and AP mode for Android devices through NFC.
- Dual-lens camera with H.264 compression and a 2 MP resolution provides clear video capture.
Ideal Use Cases
The DS-K6B630TX is perfect for indoor environments where heightened security alongside visitor management is essential. Suitable for offices, corporate buildings, and institutional facilities, this swing barrier ensures controlled access with a sleek design.
