Hikvision DS-8001HMI Mobile DVR 1 SATA Interface

Technical Specification

Features:
  • Make: Hikvision
  • Model code: DS-8001HMI
  • Channels: 1
  • Recording Mode: Real Time / Timelapse
  • Monitor Outputs: 1 x BNC (1.0 Vp-p, 75 Ohm)
Read more
Additional info:

Network interface: 1, RJ45 10M/100M Ethernet Port, 1 RJ45 RS232 Port. 1 SATA interface.

Read more
Make Hikvision
Manufacturer Hikvision USA Inc.
Model code DS-8001HMI
Channels 1
Recording Mode Real Time / Timelapse
Monitor Outputs 1 x BNC (1.0 Vp-p, 75 Ohm)
Alarm I/O 4 in / 2 out
Storage Capacity GB 2000
Image per second (IPS) 25 fps (PAL) / 30 fps (NTSC)
Compression Type H.264
Resolution PAL: 704 x 576, NTSC: 704 x 480
Signal Mode PAL, NTSC
Recording System HDD
Mount type 1 in, 1 out
Physical Specifications Dimensions mm: 290 x 225 x 90
Weight kg: 5
Electrical Specifications Voltage: 12 V DC
Power Consumption: 26 W
Environmental Specifications Operating Temp oC: -20 ~ +65
Operating Humidity %: 10 ~ 95
Additional info

Network interface: 1, RJ45 10M/100M Ethernet Port, 1 RJ45 RS232 Port. 1 SATA interface.

Download PDF version
