Hanwha Techwin HCD-6010 2MP Analog HD Indoor Dome

Technical Specification

Features:
  • Make: Hanwha Techwin
  • Model code: HCD-6010
  • Chip Inch Size: 1/3
  • Color Type: Color / Monochrome
  • Resolution TVL: 2 MP
Read more
Additional info:

Full HD resolution 0.27Lux@F2.0(Color), 0.017Lux 2.8mm wide-angle lens Day & Night(ICR), WDR(120dB) SSNRⅣ, Motion detection Transmission distance 1640ft Easy installation (Plug & play), 12VDC Multi-protocol compatible with AHD, TVI, CVI, CVBS

Read more
Make Hanwha Techwin
Manufacturer Hanwha Techwin America
Model code HCD-6010
Chip Inch Size 1/3
Color Type Color / Monochrome
Resolution TVL 2 MP
HD Yes
Sensitivity lux 0.017 ~ 0.27
Indoor/Outdoor Indoor
Electrical Specifications Voltage: 12 V DC
Power Consumption: 3.6W
Focal length 2.8mm
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1 ~ 1/12,000sec
Network Properties Image Frame Rate: 30 fps
Physical Specifications Dimensions mm: Ø110 x 86
Weight g: 221g
Environmental Specifications Operating Temp oC: -10 ~ +55 C (14 ~ 131 F)
Operating Humidity %: <90
Additional info
  • Full HD resolution
  • 0.27Lux@F2.0(Color), 0.017Lux
  • 2.8mm wide-angle lens
  • Day & Night(ICR), WDR(120dB)
  • SSNRⅣ, Motion detection
  • Transmission distance 1640ft
  • Easy installation (Plug & play), 12VDC
  • Multi-protocol compatible with AHD, TVI, CVI, CVBS
Download PDF version Download PDF version
