CDVI UK A22K-POE High Security PoE Ultra Controller/expander

Technical Specification

Features:
  • Make: CDVI UK
  • Model code: A22K-POE
  • Controller Type: Networkable
  • Max No. of Doors per Controller: 2
  • No of Cardholders: 10,000
Read more
Additional info:

2 doors and 4 readers controller/ expander Area capacity management for social distancing 66 Watts PoE enabled Includes free software & free app Up to 500 doors and 10,000 users & cards

Read more
Make CDVI UK
Manufacturer CDV International
Model code A22K-POE
Controller Type Networkable
Max No. of Doors per Controller 2
No of Cardholders 10,000
Communication Type On-board Ethernet: A22K-POE to A22K-POE (max 50 IP-IP), Bus: RS-485 A22K-POE (max 4 per A22K-POE), Auto: detect hardware modules (No DIP Switches)
Onboard No/Type of Inputs / Outputs Multi-purpose inputs: 6 (or 12 using zone doubling) / Auxiliary outputs: 1A (12Vdc) Fuseless protection , Lock outputs: 2 x (750mA @ 12Vdc) , Relay outputs: 2 x Form C relays (Dry Contact) 5A @ 250Vac, 7A @ 125Vac, 7A @ 30Vdc
Universal / Wiegand Reader Interface Yes
Reader Max. Distance m 100
Electrical Specifications Voltage: 56 V DC
Environmental Specifications Operating Temp oC: -20 ~ +50 C (-4 ~ +122 F)
Additional info
  • 2 doors and 4 readers controller/ expander
  • Area capacity management for social distancing
  • 66 Watts PoE enabled
  • Includes free software & free app
  • Up to 500 doors and 10,000 users & cards
