Briton 3934.SSS Electromagnetic Overhead Closer
Technical Specification
- Make: Briton
- Model code: 3934.SSS
- Door Closers: Yes
- Accessories: Electromagnetic Overhead Closer
Low projection template adjustable closing power size EN 3-4 door & transom mount, EN 3 parallel arm mount applications Certified, UKCA & CE marked for door mount pull, transom mount push and parallel arm mount applications Catch plate can be set to operate in hold-open or swing-free at the point of installation Adjustable closing speed & latch action Designed for use on low voltage circuits 24v DC linked to a fire alarm Supplied with armset and brackets for door mount, transom or parallel mounting Electromagnet is controlled by the building fire alarm/detector and activates the ‘catch plate’ to ensure the door closes automatically in the event of a fire or power failure Test switch simulates fire condition to check operation Supplied with flexible armoured power loop (330mm long as standard) to run power safely from the door frame to the closer
Read more| Make | Briton |
|---|---|
| Manufacturer | Allegion plc |
| Category | Access Control>Access control accessories |
| Model code | 3934.SSS |
| Door Closers | Yes |
| Accessories | Electromagnetic Overhead Closer |
Product description
Briton 3934.SSS Electromagnetic Overhead Closer
The Briton 3934.SSS Electromagnetic Overhead Door Closer is essential for ensuring both safety and convenience in high-traffic areas. Designed specifically for environments like care homes and school corridors, this door closer enhances accessibility while maintaining fire safety. It features reliable hold-open and swing-free functions, automatically closing doors in fire emergencies when connected to a building's fire alarm or smoke detection system.
Key Features
- UKCA and CE marked for compliance and certified for various mounting applications.
- Operates on low voltage circuits (24v DC), seamlessly integrating with fire alarm systems.
- Offers adjustable closing speed, latch action, and backcheck for tailored performance.
- Comes with necessary armset and brackets for door, transom, or parallel mounting.
- Available in silver and satin stainless steel finishes, with a softline cover.
Ideal Use Cases
This door closer is perfect for heavy traffic areas where unobstructed access is critical, such as healthcare facilities or educational institutions. It allows for smooth passage under normal conditions, while ensuring rigorous fire safety by autonomously closing in emergencies.
