Visionhitech VN70B-H4IR CCTV Camera

Technical Specification

Features:
  • Make: Visionhitech
  • Model code: VN70B-H4IR
  • Chip Inch Size ": 1/3
  • Resolution TVL: 420
  • Digital (DSP): Yes
Read more
Additional info:

VN70B-H4IR CCTV Camera from Visionhitech

Read more
Make Visionhitech
Manufacturer Visionhitech Co., Ltd
Model code VN70B-H4IR
Chip Inch Size " 1/3
Resolution TVL 420
Digital (DSP) Yes
Electrical Specifications Voltage: 12 VDC
Focal Length mm 4.3
Picture Elements HxV 512 x 492
Back Light Compensation Yes
Auto Gain Control Yes
Gamma Correction 0.45
Electronic Shutter range 1/60~1/100,000 sec
S/ N (Signal/ Noise) Ratio dB > 50
Synchronisation Internal
Signal Mode PAL, NTSC
Video Output 1.0Vp-p Composite. 75 Ohms
Physical Specifications Dimension mm: 70 x 95
Weight g: 1100
Environmental Specifications Operating Temperature oC: -10 ~ +50
Protection: IP67
Operating Humidity %: 0 ~ 90
Additional info VN70B-H4IR CCTV Camera from Visionhitech
Download PDF version
