Vicon NETSWITCH-24-POE-1 24-Port Gigabit Network Switch With PoE

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Vicon NETSWITCH-24-POE-1 24-Port Gigabit Network Switch With PoE

Features:

Make: Vicon
Model code: NETSWITCH-24-POE-1
Switcher Type: IP
POE: Yes
Video inputs / ports: 24

Additional info:

24 RJ-45 10/100 ports, 2 RJ-45 10/100/1000 ports and 2 mini-GBIC expansion ports Provides PoE power that eliminates the need for a separate power supply Forwards and filters data at full wire speed Provides store-and-forward switching Supports half duplex and full duplex modes auto-negotiating for all ports Secure control with SSL for browser-based interface Convenient rack-mount installation

Contact manufacturer Contact manufacturer

Make	Vicon
Manufacturer	Vicon Industries
Category	Video Surveillance>Switchers & Switches
Model code	NETSWITCH-24-POE-1
Switcher Type	IP
POE	Yes
Video inputs / ports	24
Physical Specifications	Dimensions mm: 45 x 430 x 350 Weight g: 4,100
Electrical Specifications	Voltage: 100 ~ 240 V AC Power Consumption: 15.4 W
Environmental Specifications	Operating Temperature ^oC: 0 ~ 50 C (32 ~ 122 F) Operating Humidity %: 10 ~ 95
Additional info	24 RJ-45 10/100 ports, 2 RJ-45 10/100/1000 ports and 2 mini-GBIC expansion ports Provides PoE power that eliminates the need for a separate power supply Forwards and filters data at full wire speed Provides store-and-forward switching Supports half duplex and full duplex modes auto-negotiating for all ports Secure control with SSL for browser-based interface Convenient rack-mount installation
