Uniview (UNV) UAC-T115-AF28-W 5MP ColorHunter Fixed Warm Light Turret Analog Camera
Technical Specification
- Make: Uniview (UNV)
- Model code: UAC-T115-AF28-W
- Series: Dolphin Series
- Color Type: Color / Monochrome
- Resolution TVL: 5 MP
5MP high quality image TVI/AHD/CVI/CVBS Supports white light illumination, 24/7 color images Supports 180° horizontal flip, 180° vertical flip OSD configuration menu, easy to operate IP67 waterproof and dustproof design, high reliability OSD configuration menu in 11 languages Built-in microphone for high quality audio transmission via coaxial cables
Read more| Make | Uniview (UNV) |
|---|---|
| Manufacturer | Zhejiang Uniview Technologies Co.,Ltd |
| Category | Video Surveillance>Surveillance cameras |
| Model code | UAC-T115-AF28-W |
| Series | Dolphin Series |
| Color Type | Color / Monochrome |
| Resolution TVL | 5 MP |
| Sensitivity lux | 0.01 lux (F1.6, AGC ON) ; 0 lux (white light on) |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: MAX 2.3W |
| Focal Length mm | 2.8 mm |
| Mount Type | Corner, Pole, Wall, Pendant |
| Wide Dynamic Range | Yes |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | PAL: 1/25s-1/50000s， NTSC: 1/30s-1/50000s |
| Video Output | BNC, supports TVI/AHD/CVI/CVBS |
| Physical Specifications |
Dimension mm: Φ118 x 96 Weight g: 210g |
| Environmental Specifications |
Operating Temperature oC: -30 ~ +60 C (-22 ~ +140 F) Protection: IP67 Operating Humidity %: < 95 |
Product description
Uniview UAC-T115-AF28-W: 5MP ColourHunter Fixed Turret Analog Camera
The Uniview UAC-T115-AF28-W is a robust 5MP ColourHunter fixed turret analog camera designed to offer high-quality, color-rich surveillance in any lighting condition. Equipped with a 1/2.7-inch CMOS sensor, it supports multiple types of video output, including TVI, AHD, CVI, and CVBS, enhancing adaptability and networking solutions for diverse installations.
Key Features
- High-Resolution Imaging: Capture 5MP images with crisp clarity.
- 24/7 Color Video: White light illumination ensures vivid color images around the clock.
- Built-in Microphone: Supports high-quality audio transmission via coaxial cables.
- Flexible Installation: Features 180° horizontal and vertical flip for versatile placement.
- User-Friendly Interface: Includes an OSD configuration menu available in 11 languages for ease of operation.
- IP67 Protection: Waterproof and dustproof design ensures durability in harsh environments.
Ideal Use Cases
The UAC-T115-AF28-W is perfect for outdoor surveillance in commercial and industrial settings. Its weather-resistant design and ability to maintain color video make it ideal for continuous monitoring in variable lighting conditions. Additionally, the built-in audio feature supports comprehensive security coverage in secure environments like warehouses and parking lots.
