Uniview (UNV) UAC-T112-F40-W-X 2MP ColorHunter Fixed Turret Analog Camera
Technical Specification
- Make: Uniview (UNV)
- Model code: UAC-T112-F40-W-X
- Series: Dolphin Series
- Chip Inch Size ": 1/3
- Color Type: Color / Monochrome
2MP high quality image TVI/AHD/CVI/CVBS Supports white light illumination, 24/7 full-color imaging Supports 180° horizontal flip, 180° vertical flip OSD configuration menu, easy to operate IP67 waterproof and dustproof design, high reliability OSD configuration menu in 11 languages 3D noise reduction technology delivers clean and sharp images 3-Axis
Read more| Make | Uniview (UNV) |
|---|---|
| Manufacturer | Zhejiang Uniview Technologies Co.,Ltd |
| Category | Video Surveillance>Surveillance cameras |
| Model code | UAC-T112-F40-W-X |
| Series | Dolphin Series |
| Chip Inch Size " | 1/3 |
| Color Type | Color / Monochrome |
| Resolution TVL | 2MP |
| Sensitivity lux | 0.01 lux (F1.6, AGC ON) ; 0 lux (white light on) |
| Electrical Specifications |
Voltage: 12 V DC Power Consumption: MAX 2.0W |
| Focal Length mm | 4.0 mm |
| Mount Type | Corner, Pole, Wall, Pendant |
| Wide Dynamic Range | Yes |
| Back Light Compensation | Yes |
| Auto Gain Control | Yes |
| White Balance | Yes |
| Electronic Shutter range | PAL: 1/25s-1/50000s， NTSC: 1/30s-1/50000s |
| Video Output | BNC, supports TVI/AHD/CVI/CVBS |
| Physical Specifications |
Dimension mm: Φ118 x 96 Weight g: 205g |
| Environmental Specifications |
Operating Temperature oC: -30 ~ +60 C (-22 ~ +140 F) Protection: IP67 Operating Humidity %: < 95 |
Product description
Uniview UAC-T112-F40-W-X: Advanced 2MP ColorHunter Analog Camera
The Uniview UAC-T112-F40-W-X is a cutting-edge 2MP ColorHunter Fixed Warm Light Turret Analog Camera, engineered to provide exceptional image clarity and continuous full-color surveillance. Equipped with a robust 1/3-inch CMOS sensor, this camera supports multiple video formats including TVI, AHD, CVI, and CVBS, ensuring unparalleled adaptability for diverse networking requirements.
Distinctive Features
- Superior Imaging: Offers 2MP high-quality images for detailed monitoring.
- Full-Color Imaging: With white light illumination, it delivers 24/7 color-enhanced visuals.
- Performance Configuration: OSD configuration menu available in 11 languages for user-friendly setup.
- Weatherproof Design: IP67 rating ensures durability in harsh environments.
- 3D Noise Reduction: Reduces noise to produce clear and sharp images.
- Flexible Installation: Supports multiple mounting options including wall, pole, corner, and pendant configurations.
Ideal Use Cases
The Uniview UAC-T112-F40-W-X is ideal for environments requiring continuous and reliable surveillance such as warehouses, retail stores, and parking lots. Its capability to perform in low light conditions, paired with resilient build quality, makes it perfect for both indoor and outdoor settings.
Technical Specifications
- Resolution: 1080P with adjustable frame rates.
- Lens: 4.0 mm lens with a wide viewing angle of 82.5° (H).
- Illumination: Achieves low-light performance with a minimum illumination of 0.01 lux.
- Protection: Built-in 4 KV surge protection for both power and video output interfaces.
