MobileView MSS-7008-VHS 520 TVL IP67 IR Wedge Camera

Technical Specification

Features:
  • Make: MobileView
  • Model code: MSS-7008-VHS
  • Chip Inch Size ": 1/3
  • Resolution TVL: 520
  • Digital (DSP): Yes
Read more
Additional info:

MobileView MSS-7008-VHS 520 TVL IP67 IR wedge camera is ideally suited for exterior transit vehicle applications.

Read more
Make MobileView
Manufacturer Interlogix
Model code MSS-7008-VHS
Chip Inch Size " 1/3
Resolution TVL 520
Digital (DSP) Yes
Specialist Types Infrared
Sensitivity lux 0.4
Electrical Specifications Voltage: 12 V DC
Power Consumption: 8 W
Focal Length mm 2.9 ~ 10
Picture Elements HxV 768 x 494
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Gamma Correction 0.45
Electronic Shutter range 1/50 (1/60) ~ 1/100,000
S/ N (Signal/ Noise) Ratio dB > 48
Signal Mode PAL, NTSC
Video Output BNC 1.0Vp-p , 75 ohm
Physical Specifications Dimension mm: 70 x 50 x 22
Weight g: 60
Environmental Specifications Protection: IP67
Additional info MobileView MSS-7008-VHS 520 TVL IP67 IR wedge camera is ideally suited for exterior transit vehicle applications.
