Bosch LTC 5231/90 Video signal device
Technical Specification
- Make: Bosch
- Model code: LTC 5231/90
- Video Distribution Amplifier: Yes
- No of Video Inputs: 1
- No of Video Outputs: 4
The LTC 5231 series are single-channel video distribution amplifiers. They provide 4 video outputs, identical to a single video input, for use with other video equipment. A front panel LED is provided, to indicate when the amplifier is receiving video. In the event of loss of video, the LTC 5231 series amplifiers provide a relay contact closure output to signal this occurrence. The LTC 5231 units are supplied as desktop units. Rack mount kits are available for rack mounting.
Read moreMake | Bosch |
---|---|
Manufacturer | Bosch Security Systems |
Category | Video Surveillance>Video signal devices & accessories |
Model code | LTC 5231/90 |
Video Distribution Amplifier | Yes |
No of Video Inputs | 1 |
No of Video Outputs | 4 |
Bandwidth MHz | 33 |
Signal-to-Noise Ratio dB | -72 |
Differential Gain % | 0.7 |
Physical Specifications |
Dimensions mm: 41 x 234 x 262 Weight g: 1500 |
Environmental Specifications |
Operating Temperature oC: 0 ~ 50 Operating Humidity %: 20 ~ 90 |
Electrical Specifications |
Voltage: 230 V AC Power Consumption: 3.5 W |
Additional info | The LTC 5231 series are single-channel video distribution amplifiers. They provide 4 video outputs, identical to a single video input, for use with other video equipment. A front panel LED is provided, to indicate when the amplifier is receiving video. In the event of loss of video, the LTC 5231 series amplifiers provide a relay contact closure output to signal this occurrence. The LTC 5231 units are supplied as desktop units. Rack mount kits are available for rack mounting. |
Download PDF version Download PDF version |
