ASSA ABLOY OUCME - Offline Update On Card Management Equipment
Technical Specification
- Make: ASSA ABLOY
- Model code: OUCME
- Reader Type: Card Swipe
- Read Range mm: 10
- LED / Beep: LED (Red and Green)
Application Registering cards without the need to go to the lock with the portable programmer or passing a new card through the lock Collecting events recorded on the locks via the user's card: control of their activities, authorized or unauthorized access attempts, etc. Control of the battery status of the locks without the need to test the lock Registering users without the need to reprogram the lock Enables different credentials formats to be used Offers the possibility of multi-application of pre-payment, loyalty, POS programs etc. Specification Reader module Read/write contactless chip identification technology RFID 13.56MHz ISO14443A Phillips MIFARE CLASSIC 1K and 4K and ULTRALIGHT Reading distance: 10mm with standard credentials Compatible with mobile phones NFC Red and green warning LED Control Unit Non-volatile memory Operating modes - Standard: Default operating mode, credentials must be moved close by - First user: Lock in passageway after first access of an authorized user Connections Connector from the power cable to the power supply Ethernet TCP/IP connector PS/2 connector VGA connector for the screen Connection via relay output and power supply to electromechanical lock (electrical door locking) Connection to back-up battery in the event of a power supply failure Power cable included with the following characteristics: Input: 100-240Vac 50/60Hz, 1A Output: 7.5V - 1.2A Operating conditions Humidity: Up to 85% without condensation (Interior drainage in the reader Temperature between -10°C and 80°C IP54
Read moreMake | ASSA ABLOY |
---|---|
Manufacturer | ASSA ABLOY |
Model code | OUCME |
Reader Type | Card Swipe |
Read Range mm | 10 |
LED / Beep | LED (Red and Green) |
Color | Black and Stainless Steel |
Electrical Specifications | Voltage: 100 ~ 240 V AC |
Environmental Specifications |
Operating Temp oC: -10 ~ +80 C (14 ~ 176 F) Operating Humidity %: 85 |
Protection | IP54 |
Additional info |
Application
Specification Reader module
Control Unit
- Standard: Default operating mode, credentials must be moved close by - First user: Lock in passageway after first access of an authorized user Connections
Operating conditions
|
Download PDF version Download PDF version |
