Technical Specification

Features:
  • Make: American Dynamics
  • Model code: ADC522WP
  • Series: ADC520 Series
  • Chip Inch Size ": 1/3
  • Color Type: Monochrome
Read more
Additional info:

The ADC522WP is a weather resistant tube design. The built in IR illumination LEDs allow this camera to produce a picture with 0 lux ambient light. The 12 IR LEDs provide coverage up to 10 meters to deliver a sharp picture while producing no visible light. In low light when the IR illuminators are operating the camera electronically switches to monochrome.

Read more
Make American Dynamics
Manufacturer Tyco International
Model code ADC522WP
Series ADC520 Series
Chip Inch Size " 1/3
Color Type Monochrome
Resolution TVL 380
Specialist Types Infrared
Sensitivity lux 0.5 @ F2.0
Electrical Specifications Voltage: 12 V DC
Power Consumption: 120
Focal Length mm 4.0
Picture Elements HxV 510 x 492
Auto Gain Control Yes
Electronic Shutter range 1/60 ~ 1/100,000
S/ N (Signal/ Noise) Ratio dB >48
Synchronisation Internal
Signal Mode EIA
Physical Specifications Dimension mm: 65 (Dia) x 105
Weight g: 550
Environmental Specifications Operating Temperature oC: -10 ~ +50
Protection: IP57
Additional info The ADC522WP is a weather resistant tube design. The built in IR illumination LEDs allow this camera to produce a picture with 0 lux ambient light. The 12 IR LEDs provide coverage up to 10 meters to deliver a sharp picture while producing no visible light. In low light when the IR illuminators are operating the camera electronically switches to monochrome.
