Altronix eBridge1STR EoC Single Port Adapter Kit

Technical Specification

Features:

Make: Altronix
Model code: eBridge1STR
Data Transceiver: Yes
Receiver Type: Yes
No of Video Inputs: 1

Additional info:

Altronix eBridge1STR ethernet over coax adapter kit transmits data at 25Mbps and power over Coax cable in a PoE+ compliant format. The eBridge1PCRM is powered by an external midspan or endspan. The eBridge1PCRM receiver passes PoE/PoE+ power over the same coax cable to the eBridge1ST transceiver, which, in turn, passes this power to an enabled IP camera/device. These plug and play units facilitate a cost-effective, simple way to replace legacy analog products with new IP devices over existing coax up to 500m.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Altronix
Manufacturer	Altronix
Model code	eBridge1STR
Data Transceiver	Yes
Receiver Type	Yes
No of Video Inputs	1
Physical Specifications	Dimensions mm: 89 x 25 x 89 Weight g: 180
Environmental Specifications	Operating Temperature ^oC: -40 ~ +75 C (-40 ~ +167 F) Operating Humidity %: 20 ~ 85
Additional info	Altronix eBridge1STR ethernet over coax adapter kit transmits data at 25Mbps and power over Coax cable in a PoE+ compliant format. The eBridge1PCRM is powered by an external midspan or endspan. The eBridge1PCRM receiver passes PoE/PoE+ power over the same coax cable to the eBridge1ST transceiver, which, in turn, passes this power to an enabled IP camera/device. These plug and play units facilitate a cost-effective, simple way to replace legacy analog products with new IP devices over existing coax up to 500m.
