Altronix EBridge100STR EoC Single Port Adapter Kit

Technical Specification

Features:
  • Make: Altronix
  • Model code: eBridge100STR
  • Data Transceiver: Yes
  • Receiver Type: Yes
  • No of Video Inputs: 1
Additional info:

eBridge100STR is a versatile solution Ethernet adapter/media converter kit which transmits data at 100Mbps full duplex and power over Coax cable in a PoE+ compliant format. The eBridge100RM is powered via a PoE midspan, such as the Altronix Netway series, or by an endspan. The receiver passes the PoE(+) compliant power over cable to the eBridge100ST transceiver which in turn passes this power to an enabled IP Camera/device. These plug and play units facilitate cost effective solutions for IP devices that need to be installed at distances greater than 100m. They provide a simple way to replace legacy analog products with new IP devices over existing coax.

Read more
Make Altronix
Manufacturer Altronix
Model code eBridge100STR
Data Transceiver Yes
Receiver Type Yes
No of Video Inputs 1
Physical Specifications Dimensions mm: 89 x 25 x 89
Weight g: 110
Environmental Specifications Operating Temperature oC: -40 ~ +75 C (-40 ~ +167 F)
Operating Humidity %: 20 ~ 85
Additional info

eBridge100STR is a versatile solution Ethernet adapter/media converter kit which transmits data at 100Mbps full duplex and power over Coax cable in a PoE+ compliant format. The eBridge100RM is powered via a PoE midspan, such as the Altronix Netway series, or by an endspan. The receiver passes the PoE(+) compliant power over cable to the eBridge100ST transceiver which in turn passes this power to an enabled IP Camera/device. These plug and play units facilitate cost effective solutions for IP devices that need to be installed at distances greater than 100m. They provide a simple way to replace legacy analog products with new IP devices over existing coax.
