Technical Specification

Features:
  • Make: Software House
  • Model code: RM2L-PH
  • Series: RM Series
  • Long Range: Yes
  • Reader Type: Proximity
Read more
Additional info:

The LCD is an optional backlit text display which is available with any RM card reader.  It provides card holders with visual feedback and prompts, such as "Access Granted" or "Enter PIN".  The display consists of two lines of 16 characters and can be configured to display custom messages.  The LCD is designed to be used with readers that have a keypad and is not recommended for use in harsh temperatures.

Read more
Make Software House
Manufacturer Tyco International
Model code RM2L-PH
Series RM Series
Long Range Yes
Reader Type Proximity
Standalone/ Networkable Standalone
Keypad Integrated Yes
Read Range mm 114
LED / Beep LED / Beep
Electrical Specifications Voltage: 12 V DC
Power Consumption: 350 mA
Physical Specifications Dimensions mm: 129.5 x 142.2 x 49.5
Weight g: 280
Environmental Specifications Operating Temp oC: 0 ~ 50
Operating Humidity %: 0 ~ 95
Protection Weather Resistant
Additional info

The LCD is an optional backlit text display which is available with any RM card reader.  It provides card holders with visual feedback and prompts, such as "Access Granted" or "Enter PIN".  The display consists of two lines of 16 characters and can be configured to display custom messages.  The LCD is designed to be used with readers that have a keypad and is not recommended for use in harsh temperatures.
