Schlage (Allegion) RC11 Mullion Mount IP Reader Controller
Technical Specification
- Make: Schlage (Allegion)
- Model code: RC11
- Controller Type: Networkable
- Networkable: Yes
- Onboard No/Type of Inputs / Outputs: Inputs: Request to Exit (REX) / Auxiliary Input (AUX) / Door Position Switch (DPS)
The RC11 mullion mount is a next-generation IP reader controller designed for scalable and flexible real-time access control in perimeter and high security applications. The all-in-one device leverages the comprehensive ecosystem from Schlage and offers simplified architecture, installation and integration into open PACS solutions, including Pure Access Cloud.
Read more| Make | Schlage (Allegion) |
|---|---|
| Manufacturer | Allegion plc |
| Category | Access Control>Access control controllers |
| Model code | RC11 |
| Controller Type | Networkable |
| Networkable | Yes |
| Onboard No/Type of Inputs / Outputs | Inputs: Request to Exit (REX) / Auxiliary Input (AUX) / Door Position Switch (DPS) |
| Electrical Specifications | Voltage: DC power: 10 ~ 13 V DC, PoE or PoE+ (IEEE 802.3af, Class 0) |
| Physical Specifications |
Dimensions mm: 151 x 45 x 25 Weight g: 164.4 |
| Environmental Specifications |
Operating Temp oC: -40 ~ +66 C (-31 ~ +151 F) Protection: IP65 |
| Additional info |
The RC11 mullion mount is a next-generation IP reader controller designed for scalable and flexible real-time access control in perimeter and high security applications. The all-in-one device leverages the comprehensive ecosystem from Schlage and offers simplified architecture, installation and integration into open PACS solutions, including Pure Access Cloud. |
