Raytec RM300-PLT-AI-05 Illuminator With Distance Up To 1000 M
Technical Specification
- Make: Raytec
- Model code: RM300-PLT-AI-05
- Series: RAYMAX 300
- LED Type: IR
- Lamp Type: Narrow
The RM300 PLATINUM is the latest generation of the RAYMAX series, designed specifically for long distance or wide angle applications. RM300-PLT provides World class performance, long life and zero maintenance. RM300-PLT incorporates the very latest surface mount LED's to deliver excellent night-time pictures with improved optical output and outstanding reliability.
Read more| Make | Raytec |
|---|---|
| Manufacturer | Raytec Ltd |
| Category | Video Surveillance>Security camera lighting |
| Model code | RM300-PLT-AI-05 |
| Series | RAYMAX 300 |
| LED Type | IR |
| Lamp Type | Narrow |
| Distance | 700 |
| Width | 5 x 15 |
| Filter nM | 850 |
| Photocell | Yes |
| Physical Specifications |
Dimensions mm: 420 x 195 x 66 Weight kg: 6 |
| Electrical Specifications |
Voltage: 13.5 V Power Consumption: 120 W |
| Environmental Specifications |
Operating Temperature oC: -50 ~ +50 Protection: IP66 |
| Additional info |
The RM300 PLATINUM is the latest generation of the RAYMAX series, designed specifically for long distance or wide angle applications. RM300-PLT provides World class performance, long life and zero maintenance. RM300-PLT incorporates the very latest surface mount LED's to deliver excellent night-time pictures with improved optical output and outstanding reliability. |
