Technical Specification

Features:
  • Make: Omnitek
  • Model code: OP45
  • Series: OmniProx Series
  • Reader Type: Proximity
  • Long Range: Yes
Additional info:

OP45 proximity card reader offers reliability, consistent read range and low power consumption with an easy to install package. OP45 is available in an HID compatible card format as well as an ADEMCO compatible card format. OP45 is designed to mount on a US size electrical box or be surface mounted. ADA compliant built-in audible buzzer. Host LED Control and Tamper Output. Wiegand Output.

Read more
Make Omnitek
Manufacturer Honeywell
Model code OP45
Series OmniProx Series
Reader Type Proximity
Long Range Yes
Environmental Specifications Operating Temperature oC: -31 ~ +63
Protection: Weather Resistant, Vandal Resistant
Electrical Specifications Voltage: 4.75 ~ 16
Physical Specifications Dimensions mm: 90 x 90 x 15
Additional info OP45 proximity card reader offers reliability, consistent read range and low power consumption with an easy to install package. OP45 is available in an HID compatible card format as well as an ADEMCO compatible card format. OP45 is designed to mount on a US size electrical box or be surface mounted. ADA compliant built-in audible buzzer. Host LED Control and Tamper Output. Wiegand Output.
Download PDF version
