Hunt Electronics HTC-2N8 Surveillance camera

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Features:

Make: Hunt Electronics
Model code: HTC-2N8
Chip Inch Size ": 1/4
Color Type: Color
Resolution TVL: 480

Additional info:

DSP Board Camera. Night vision available for colour camera. 2H Mode Aperture Correction. Picture element (Sharp chip) : 771 x 492 (NTSC). Synchronisation : Internal (DC type) / Line lock (AC type). Auto Back light compensation and Gain Control. Lenses available : 2.9mm, 3.7mm, 6mm, 8mm and 12mm. Verifocal auto iris lens / board lens available.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Hunt Electronics
Manufacturer	Hunt Electronics USA, Inc.
Category	Video Surveillance>Surveillance cameras
Model code	HTC-2N8
Chip Inch Size "	1/4
Color Type	Color
Resolution TVL	480
Digital (DSP)	Yes
Specialist Types	PCB
Auto Iris	Yes
Sensitivity lux	2.0
Direct Drive	Yes
Electrical Specifications	Voltage: 12 Power Consumption: 200
Focal Length mm	3.6
Picture Elements HxV	753 x 582 (PAL)
Back Light Compensation	Yes
Auto Gain Control	Yes
White Balance	Yes
Gamma Correction	0.45
Electronic Shutter range	1/50 ~ 1/100,000
S/ N (Signal/ Noise) Ratio dB	> 48
Synchronisation	Internal / Line-lock
Signal Mode	PAL / NTSC
Physical Specifications	Dimension mm: 32 x 32 Weight g: 20
Environmental Specifications	Operating Temperature ^oC: -10 ~ +45
Additional info	DSP Board Camera. Night vision available for colour camera. 2H Mode Aperture Correction. Picture element (Sharp chip) : 771 x 492 (NTSC). Synchronisation : Internal (DC type) / Line lock (AC type). Auto Back light compensation and Gain Control. Lenses available : 2.9mm, 3.7mm, 6mm, 8mm and 12mm. Verifocal auto iris lens / board lens available.
