HID R40

Technical Specification

Please note: this is a discontinued product.

Go to Replacement product

Features:

Make: HID
Model code: R40
Series: iCLASS Series
Long Range: Yes
Reader Type: Smart Card

Additional info:

The R40 is designed to mount and cover single gang switch boxes primarily used in the United States and includes a slotted mounting plate for European and Asian back box spacing. iCLASS Card : Up to 4.25”. iCLASS Key/Tag : Up to 2”. MIFARE / DESFire Card (CSN) : Up to 2.5”. 13.56 MHz transmission frequency.

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	HID
Manufacturer	HID
Category	Access Control>Access control readers
Model code	R40
Long Range	Yes
Reader Type	Smart Card
Standalone/ Networkable	Standalone
IP Rating	IP55
Mount Type	Wall
Read Range mm	up to 108
LED / Beep	LED / Beep
Color	Black / Gray
Wiegand Interface	Yes
Clock-and-Data Interface	Yes
Electrical Specifications	Voltage: 5 ~ 16 V DC Power Consumption: 50/75 mA @ 12 VDC
Physical Specifications	Dimensions mm: 84 x 122 x 24
Environmental Specifications	Operating Temp ^oC: -40 ~ +65 Operating Humidity %: 5 ~ 95
Protection	Weather Resistant
Additional info	The R40 is designed to mount and cover single gang switch boxes primarily used in the United States and includes a slotted mounting plate for European and Asian back box spacing. iCLASS Card : Up to 4.25”. iCLASS Key/Tag : Up to 2”. MIFARE / DESFire Card (CSN) : Up to 2.5”. 13.56 MHz transmission frequency.
