EMX TRES-100-P-300-HA Proximity Reader
Technical Specification
- Make: EMX
- Model code: TRES-100-P-300-HA
- Reader Type: Proximity
- Mount Type: Mullion
- Read Range mm: 126
Versatile mounting options – adaptable to various surfaces including metal door and window frames Passive devices, no battery required, reducing maintenance needs Compliant with FCC, ICC, CE, C-Tick, UL Standard 294, and IP67 certifications
Read more| Make | EMX |
|---|---|
| Manufacturer | EMX Industries Inc. |
| Category | Access Control>Access control readers |
| Model code | TRES-100-P-300-HA |
| Reader Type | Proximity |
| Mount Type | Mullion |
| Read Range mm | 126 |
| Electrical Specifications |
Voltage: 5 ~ 16 V DC Power Consumption: 30 mA typical, 75 mA peak@ 12 VDC |
| Physical Specifications |
Dimensions mm: 43 x 81 x 18 Weight g: 85g |
| Environmental Specifications | Operating Temp oC: -40 ~ +65 C (-40 ~ +149 F) |
| Protection | IP67 |
Product description
Introducing the TRES-P-300-H-A Proximity Reader
The TRES-P-300-H-A Proximity Reader, from the EMX TRES Pyramid Series Proximity® line, is the leading choice for professionals in the electronic security industry. This device operates on a 125-kHz frequency, incorporating robust RFID technology for seamless integration with electronic access control systems, utilising the renowned Wiegand protocol.
Advanced Features
- Enhanced Security: Features such as MAXSecure™ and fleaPower™ provide additional security layers, ensuring reliable access control in various environments.
- Wide Compatibility: This model is compatible with both Pyramid Series cards and specific HID and AWID 125-kHz protocols, offering extensive flexibility in deployment.
- Durability: Rated IP67, the reader is suitable for both indoor and outdoor installations, thanks to its robust, weather-resistant construction.
Specifications at a Glance
- Mounts on mullions, fitting metal door and window frames effortlessly.
- Compact design with dimensions of 1.7"W x 3.2"H x 0.7"D, and a weight of 85g.
- Operating in temperatures ranging from -40°F to 149°F (-40°C to +65°C).
- Features a four-state LED standard (red, green, amber, and off) for status indication.
Ideal Use Cases
Perfect for security professionals requiring a reliable access control solution, the TRES-P-300-H-A Proximity Reader is designed to thrive in demanding environments, from commercial buildings to industrial sites, ensuring security and peace of mind.
