CDVI UK CAA-110P Lock Control Module

Technical Specification

Features:
  • Make: CDVI UK
  • Model code: CAA-110P
  • Voltage: 12 V DC
  • Power Consumption: 100mA
Additional info:

The CAA110P was specifically designed to simplify the connection of electromagnetic locks or heavy electrical bolts. The module is connected directly in the lock terminals of the CTV900ATR, allowing for easy and rapid installation of dual-locking doors (2 maglocks or 1 maglock and 1 door strike). The possibility to connect the CAA110 to a fire alarm ensures the instant unlocking of the doors in case of a fire. Simplifies the installation of a door with a double lock 2 x Form C relays 2 x LED's for relay status Directly plugs into the CTV900ATR Outputs 5A @ 12Vdc

Read more
Make CDVI UK
Manufacturer CDV International
Model code CAA-110P
Electrical Specifications Voltage: 12 V DC
Power Consumption: 100mA
Additional info

The CAA110P was specifically designed to simplify the connection of electromagnetic locks or heavy electrical bolts. The module is connected directly in the lock terminals of the CTV900ATR, allowing for easy and rapid installation of dual-locking doors (2 maglocks or 1 maglock and 1 door strike). The possibility to connect the CAA110 to a fire alarm ensures the instant unlocking of the doors in case of a fire.

  • Simplifies the installation of a door with a double lock
  • 2 x Form C relays
  • 2 x LED's for relay status
  • Directly plugs into the CTV900ATR
  • Outputs 5A @ 12Vdc
Download PDF version Download PDF version
