BCDVideo BCD-RSS-802U EN50155 10-port Unmanaged PoE M12 Full Giga Ethernet Switch 72/96/110 V

Technical Specification

Features:

Make: BCDVideo
Model code: BCD-RSS-802U
Switcher Type: IP
POE: Yes
Video inputs / ports: 10

Additional info:

Complies with EN50155 8 x M12 X-Coded 10/100/1000Mbps PoE ports + 2 x M12 X-Coded 10/100/1000Mbps ports with Bypass function Power Input EKI-9510G-2GPH: 72/96/110 VDC EKI-9510G-2GPL: 24/48 VDC Operating Voltage EKI-9510G-2GPH: 50.4~137.5 VDC EKI-9510G-2GPL: 16.8~60 VDC 8 IEEE802.3 at/af PoE ports M12 connector with IP40 protection

Contact manufacturer Contact manufacturer

Datasheet Datasheet

Make	BCDVideo
Manufacturer	BCDVideo
Category	Video Surveillance>Switchers & Switches
Model code	BCD-RSS-802U
Switcher Type	IP
POE	Yes
Video inputs / ports	10
Physical Specifications	Dimensions mm: 216 x 132 x 59 Weight g: 1500
Electrical Specifications	Voltage: 50.4 ~ 137.5 V DC Power Consumption: 10 W
Environmental Specifications	Operating Temperature ^oC: -40 ~ +70 C (-40 ~ +158 F) Protection: IP 40 Operating Humidity %: 10 ~ 95
Additional info	Complies with EN50155 8 x M12 X-Coded 10/100/1000Mbps PoE ports + 2 x M12 X-Coded 10/100/1000Mbps ports with Bypass function Power Input EKI-9510G-2GPH: 72/96/110 VDC EKI-9510G-2GPL: 24/48 VDC Operating Voltage EKI-9510G-2GPH: 50.4~137.5 VDC EKI-9510G-2GPL: 16.8~60 VDC 8 IEEE802.3 at/af PoE ports M12 connector with IP40 protection
