Baxall ZTX6/24M6/J Telemtry transmitters and controllers
Technical Specification
Features:
- Make: Baxall
- Model code: ZTX6/24M6/J
- Series: ZTX Series
- Telemetry Type: Coax
- Video Inputs: 24
Additional info:
With joystick. Sync/Async telemetry. Outputs individually selectable STANDARD/ALTERNATE telemetry. Outputs individually selectable STANDARD/ENHANCED preset setting. Pan and Tilt, Focus, Iris and Zoom. Auxiliaries: Camera power, Wash, Wipe, Lamps, Auto-pan, AUX 4 (all individual or global.
Read more| Make | Baxall |
|---|---|
| Manufacturer | Baxall Limited |
| Category | Video Surveillance>Telemetry transmitters and controllers |
| Model code | ZTX6/24M6/J |
| Telemetry Type | Coax |
| Video Inputs | 24 |
| Video Outputs | 6 |
| Alarm Inputs | 24in/2out |
| Presets | 8 |
| with Joystick | Yes |
| Environmental Specifications | Operating Temp oC: -10-+50ºC |
| Physical Specifications | Dimensions mm: 50 x 132 x 393mm |
| Additional info | With joystick. Sync/Async telemetry. Outputs individually selectable STANDARD/ALTERNATE telemetry. Outputs individually selectable STANDARD/ENHANCED preset setting. Pan and Tilt, Focus, Iris and Zoom. Auxiliaries: Camera power, Wash, Wipe, Lamps, Auto-pan, AUX 4 (all individual or global. |
| Download PDF version Download PDF version | |
