Altronix DL1 Door Control Timer

Technical Specification

Features:
  • Make: Altronix
  • Model code: DL1
  • Voltage: 12 ~ 24 V AC/DC
  • Dimensions mm: 38 x 102 x 19
Additional info:

Altronix DL1 is a 1 second to 1 minute door control timer that is used for basic door operation. This timer can be activated with a momentary or maintained trigger. Input12 volt - 24 volt AC or DC operation. RelayDry relay output (1 form "C" contact, rated @ 2A).12VDC regulated beeper output. FeaturesIsolated AC or DC voltage 5V-24V trigger.Time adjustable from 1 second to 1 minute.Momentary or maintained trigger. Visual IndicatorsIndicates relay is energized. TemperatureOperating 0ºC to 49ºC (32ºF to 120ºF).Storage - 20ºC to 70ºC ( - 4ºF to 158ºF).Relative Humidity 85% +/- 5%.

Read more
Make Altronix
Manufacturer Altronix
Model code DL1
Electrical Specifications Voltage: 12 ~ 24 V AC/DC
Physical Specifications Dimensions mm: 38 x 102 x 19
Additional info

Altronix DL1 is a 1 second to 1 minute door control timer that is used for basic door operation. This timer can be activated with a momentary or maintained trigger.

  • Input
    12 volt - 24 volt AC or DC operation.
  • Relay
    Dry relay output (1 form "C" contact, rated @ 2A).
    12VDC regulated beeper output.
  • Features
    Isolated AC or DC voltage 5V-24V trigger.
    Time adjustable from 1 second to 1 minute.
    Momentary or maintained trigger.
  • Visual Indicators
    Indicates relay is energized.
  • Temperature
    Operating 0ºC to 49ºC (32ºF to 120ºF).
    Storage - 20ºC to 70ºC ( - 4ºF to 158ºF).
    Relative Humidity 85% +/- 5%.
