JVC TM-H140PN Security monitor

Technical Specification

Features:
  • Make: JVC
  • Model code: TM-H140PN
  • Monitor Type: CRT
  • Effective Screen Size Inches: 14
  • Color Type: Color
Read more
Additional info:

Input A Composite 1 line, BNC connector2, 1.0V(p-p), 75 ohms, negative sync, auto-termination, bridged output possible. Input B Composite 1 line, BNC connector2, 1.0V(p-p), 75 ohms, negative sync, auto-termination, bridged output possible. Y/C 1 line, mini-DIN 4-pin2 Priority Y: 1.0V(p-p), 75 ohms, negative sync C: 0.3V(p-p), 75 ohms (PAL Burst) 0.286V(p-p), 75 ohms (NTSC Burst) auto-termination, bridged output possible.

Read more
Make JVC
Manufacturer JVC Professional Products Company
Model code TM-H140PN
Monitor Type CRT
Effective Screen Size Inches 14
Color Type Color
Resolution TVL 750
Signal Mode PAL/NTSC
Housing Material Metal
Built-in Speaker Yes
Dimensions mm 346 x 310 x 375
Electrical Specifications Power Consumption: 0.5A
Audio Connectors RCA pin X4
Video Input Connectors 1line BNC
Weight kg 13.4kg
Video Input 2
Y/ C Y/C
Additional info Input A Composite 1 line, BNC connector2, 1.0V(p-p), 75 ohms, negative sync, auto-termination, bridged output possible. Input B Composite 1 line, BNC connector2, 1.0V(p-p), 75 ohms, negative sync, auto-termination, bridged output possible. Y/C 1 line, mini-DIN 4-pin2 Priority Y: 1.0V(p-p), 75 ohms, negative sync C: 0.3V(p-p), 75 ohms (PAL Burst) 0.286V(p-p), 75 ohms (NTSC Burst) auto-termination, bridged output possible.
Download PDF version Download PDF version
