Idesco EPC 2.0 Compact Small Long Range Reader For Access Control

Technical Specification

Features:
  • Make: Idesco
  • Model code: EPC 2.0 Compact
  • Long Range: Yes
  • Reader Type: RFID
  • IP Rating: IP67
Read more
Additional info:

“Hands-free” access control, reading distance up to 4 meters Wide temperature range Supports Gen2 V2 security feature Deliverable pre-configured, or configurable with either configuration card or RS232 interface

Read more
Make Idesco
Manufacturer Idesco
Model code EPC 2.0 Compact
Long Range Yes
Reader Type RFID
IP Rating IP67
Read Range mm ≤ 4000
LED / Beep RGB Leds (VM) / Buzzer
Color Black
Wiegand Interface Yes
Electrical Specifications Voltage: 10..30 V DC (nominal 24 V DC)
Environmental Specifications Operating Temp oC: -40 ~ +85 C (-40 ~ +185 F)
Additional info
  • “Hands-free” access control, reading distance up to 4 meters
  • Wide temperature range
  • Supports Gen2 V2 security feature
  • Deliverable pre-configured, or configurable with either configuration card or RS232 interface
