Honeywell Security OM30BHOND OmniClass2 Smart Mini-Mullion Reader, Pigtail

Technical Specification

Features:
  • Make: Honeywell Security
  • Model code: OM30BHOND
  • Reader Type: Smart Card
  • IP Rating: IP55
  • Mount Type: Mullion
Read more
Additional info:

Easy to Install Available in mini and large mullion, single gang wall-mount and single gang wall-mount with keypad form factors to fit most environments—indoor or outdoor Two piece installation with mounting base and reader More Convenient Converge multiple credential technologies onto one reader platform with support for Prox, Smart and Mobile credentials Manage reader settings in the field with configuration cards or mobile app More Secure Encrypted communication between credential and reader for smart and mobile credentials Multiple encryption layers using HID’s SIO (Secure Identity Object™) and Seos™ platforms More Open Supports Secure Identity Object™ (SIO) on iCLASS SE/SR, MIFARE DESFire EV1 and MIFARE Classic* Optional HID Prox, EM4102 and AWID prox support Optional HID Mobile Access support (credential on phone) More Adaptable Interoperable with a growing range of technologies and form factors by using HID’s platform agnostic Seos™ ecosystem

Read more
Make Honeywell Security
Manufacturer Honeywell
Model code OM30BHOND
Reader Type Smart Card
IP Rating IP55
Mount Type Mullion
Reader Output format Wiegand
Read Range mm 30 ~ 80
Color Black
Wiegand Interface Yes
Physical Specifications Dimensions mm: 48 x 103 x 23
Environmental Specifications Operating Temp oC: -35 ~ +65 C (-31 ~ +149 F)
Operating Humidity %: 5 ~ 95
Additional info

Easy to Install

  • Available in mini and large mullion, single gang wall-mount and single gang wall-mount with keypad form factors to fit most environments—indoor or outdoor
  • Two piece installation with mounting base and reader

More Convenient

  • Converge multiple credential technologies onto one reader platform with support for Prox, Smart and Mobile credentials
  • Manage reader settings in the field with configuration cards or mobile app

More Secure

  • Encrypted communication between credential and reader for smart and mobile credentials
  • Multiple encryption layers using HID’s SIO (Secure Identity Object™) and Seos™ platforms

More Open

  • Supports Secure Identity Object™ (SIO) on iCLASS SE/SR, MIFARE DESFire EV1 and MIFARE Classic*
  • Optional HID Prox, EM4102 and AWID prox support
  • Optional HID Mobile Access support (credential on phone)

More Adaptable

  • Interoperable with a growing range of technologies and form factors by using HID’s platform agnostic Seos™ ecosystem
