AMAG Symmetry M2150-ELEV Elevator Controller
Technical Specification
Features:
- Make: AMAG
- Model code: Symmetry M2150-ELEV
- Controller Type: Networkable
- Max No. of Doors per Controller: 4 (cabs)
- No of Cardholders: 50,000
Additional info:
The Symmetry multiNODE 2150 Elevator controller controls and records access for up to 64 floors. Each Symmetry multiNODE 2150 elevator controller can control one, two or four elevators cabs. The Symmetry Elevator controller is con figured via client pc, allowing it to make all access decisions locally. A passenger presents a valid card at the reader and presses the button of the desired oor in the elevator cab. If the card is authorized for the selected floor, the elevator delivers the passenger to that floor.
Read more
| Make | AMAG |
|---|---|
| Manufacturer | AMAG Technology, Inc. |
| Model code | Symmetry M2150-ELEV |
| Controller Type | Networkable |
| Max No. of Doors per Controller | 4 (cabs) |
| No of Cardholders | 50,000 |
| Offline Capabilities | Yes |
| Reader Max. Distance m | 1,000 |
| Electrical Specifications | Voltage: 12 V DC |
| Environmental Specifications |
Operating Temp oC: 0 ~ 50 C (32 ~ 122 F) Operating Humidity %: 15 ~ 90 |
| Additional info | The Symmetry multiNODE 2150 Elevator controller controls and records access for up to 64 floors. Each Symmetry multiNODE 2150 elevator controller can control one, two or four elevators cabs. The Symmetry Elevator controller is con figured via client pc, allowing it to make all access decisions locally. A passenger presents a valid card at the reader and presses the button of the desired oor in the elevator cab. If the card is authorized for the selected floor, the elevator delivers the passenger to that floor. |
| Download PDF version Download PDF version | |
